Command List
Command List (5/6)
Command Set Command Command Packet Comments
CAM_PrivacyZone SetMask 8x 01 04 76 mm nn
0r 0r 0s 0s FF
mm: Mask Settings
nn 00: Modify, 01: New
rr: W, ss:H
Display 8x 01 04 77 pp pp pp pp FF Mask Display ON/OFF
pp pp pp pp: Mask Settings (0:OFF, 1:ON)
SetMaskColor 8x 01 04 78 pp pp pp pp
qq rr FF
pp pp pp pp: Mask Color Settings
qq: Color Setting when 0 is selected
rr: Color Setting when 1 is selected
SetPanTiltAngle 8x 01 04 79 0p 0p 0p
0q 0q 0q FF
Pan/Tilt Angle Settings
ppp: Pan
qqq: Tilt
SetPTZMask 8x 01 04 7B mm 0p 0p 0p
0q 0q 0q 0r 0r 0r 0r FF
Pan/Tilt/Zoom Settings for Mask
ppp: Pan, qqq: Tilt, rrrr: Zoom
Non_InterlockMask 8x 01 04 6F mm
0p 0p 0q 0q 0r 0r 0s 0s FF
mm: Non_Interlock Mask Settings
pp: X, q: Y, rr: W, ss: H
GridOn 8x 01 04 7C 02 FF Grid Display ON/OFF
GridOff 8x 01 04 7C 03 FF Grid/Center Line Display Off
CenterLineOn 8x 01 04 7C 04 FF Center Line Display On
CAM_KeyLock Off 8x 01 04 17 00 FF Camera Control Enable/Disable
On 8x 01 04 17 02 FF
CAM_IDWrite – 8x 01 04 22 0p 0q 0r 0s FF pqrs: Camera ID (=0000 to FFFF)
CAM_MemSave Write 8x 01 04 23 0m 0p 0q 0r 0s FF m: Address (=0 to 7)
pqrs: Data (0000 to FFFF)
CAM_ExtLock Internal Mode 8x 01 04 55 00 FF Internal Sync
Line Lock Mode 8x 01 04 55 01 FF V-Phase Adjustment
Frequency Lock Mode 8x 01 04 55 02 FF External Sync
CAM_VPhase Stop 8x 01 04 05 00 FF –
Up 8x 01 04 05 02 FF
Down 8x 01 04 05 03 FF
Up (Step) 8x 01 04 05 2p FF p=step (1-7)
Down (Step) 8x 01 04 05 3p FF
Reset 8x 01 04 05 40 FF Restore Factory Settings
Direct 8x 01 04 45 0p 0q 0r 0s FF pqrs: V-Phase (0000 to)
(NTSC: 0000 to 20Chex, PAL: 0000 to 270hex)
CAM_Alarm On 8x 01 04 6B 02 FF Alarm ON/OFF
Off 8x 01 04 6B 03 FF
SetMode 8x 01 04 6C pp FF pp: Mode setting
00 Focus change detection
(reference value is not updated)
01 Focus change detection (reference value is updated)
02 AE change detection (reference value is not updated)
03 AE change detection (reference value is updated)
:
0C Day/Night judgement
SetDayNighLevel 8x 01 04 6D 0p 0p 0p 0q 0q 0q FF ppp: Day judgement level setting
qqq: Night judgement level setting
Alarm(Reply) y0 07 04 6B 01 FF
Detection level “ Low”
“High”
y0 07 04 6B 00 FF
Detection level “ High”
“Low”
