Sony FCB-CX12E - Page 53

53
Command List
Others
AF Active Time
1)
00 to FF
AF Interval Time
1)
00 to FF
Spot AE X position
00 to 0F
Spot AE Y position
00 to 0F
R Gain
00 to FF
B Gain
00 to FF
Aperture Level
00 to 0F
NR Level
00 to 05
V-Phase 00 to
020C
(NTSC)
0270 (PAL)
AE Response
01 to 30
AutoICR ON
 OFF
Threshold Level
(FCB-EX15E/P, FCB-
CX15E/P)
00 to 1C
MD Threshold Level
00 to FF
MD Interval Time
1)
00 to FF
MD Set Horizontal Position
00 to 0C
MD Set Vertical Position
00 to 08
Color Enhancement
Threshold Level
00
to 7F
Color Enhancement
Hysteresis Width
00 to 7F
Color Enhancement Fixed
Color Y
00 to 7F
Color Enhancement Fixed
Color Cr
2)
00 to 7F
Color Enhancement Fixed
Color Cb
2)
00 to 7F
1)
Unit: One second
2)
40 center
Register Setting
Register No. Value
VISCA
Baud Rate
1)
00 00 9600 bps
01 19200 bps
02 38400 bps
OSD
Language
60 00 English
03 Chinese
CCD Scanning
Mode
1)
(FCB-EX15E/P,
FCB-CX15E/P:
Interlace mode
only)
72 00 Interlaced
01 Progressive
Digital Output
Mode
1)
(FCB-EX15E/P,
FCB-CX15E/P)
* Enabled when
the CCD
Scanning Mode
is Progressive.
73 00 60p/50p
(30p/25p × 2)
Clock rate:
56 MHz
01 60p/50p
Clock rate:
56 MHz
04 30p/25p
Clock rate:
28 MHz
(Stop analog output)
Zoom Limit
1)
50 00-FF Wide Limit
(0: Disabled)
51 00-FF Tele Limit
(0: Disabled)
E-Zoom Max
1)
52 00-FF Max. digital
zoom ratio =
256 ÷
(256-Value)
FocusTrace
@ZoomDirect
1)
54 00 OFF
01 ON
FocusOffset
@DomeCover
55 00-FF 00: None to
FF: Max.
1)
The register settings are enabled when the power is turned off and then
back on again. After turning the power back on again, verify that the
mode settings have been changed.
