Command List (3/7)
Command Set Command Command Packet Comments
CAM_SlowShutter On 8x 01 04 5A 02 FF Slow Shutter On/Off
Off 8x 01 04 5A 03 FF
Limit 8x 01 05 5A 0p 0q FF pq: Slow Shutter Limit
CAM_Iris Reset 8x 01 04 0B 00 FF Iris Setting
Up 8x 01 04 0B 02 FF
Down 8x 01 04 0B 03 FF
Direct 8x 01 04 4B 00 00 0p 0q FF pq: Iris Position
CAM_Gain Reset 8x 01 04 0C 00 FF Gain Setting
Up 8x 01 04 0C 02 FF
Down 8x 01 04 0C 03 FF
Direct 8x 01 04 4C 00 00 0p 0q FF pq: Gain Position
Gain Limit 8x 01 04 2C 0p FF p: Gain Limit
Gain Point Pos 8x 01 05 4C 0p 0q FF pq: Gain Point
Gain Point On/Off 8x 01 05 0C 0p FF p:2=On, 3=Off
CAM_Bright Reset 8x 01 04 0D 00 FF Bright Setting
Up 8x 01 04 0D 02 FF
Down 8x 01 04 0D 03 FF
Direct 8x 01 04 4D 00 00 0p 0q FF pq: Bright Position
CAM_ExpComp On 8x 01 04 3E 02 FF Exposure Compensation On/Off
Off 8x 01 04 3E 03 FF
Reset 8x 01 04 0E 00 FF Exposure Compensation Amount Setting
Up 8x 01 04 0E 02 FF
Down 8x 01 04 0E 03 FF
Direct 8x 01 04 4E 00 00 0p 0q FF pq: ExpComp Position 00h to 0Eh
CAM_Backlight On 8x 01 04 33 02 FF Back Light Compensation On/Off
Off 8x 01 04 33 03 FF
CAM_SpotAE On 8x 01 04 59 02 FF Spot Auto Exposure Setting
Off 8x 01 04 59 03 FF
Position 8x 01 04 29 0p 0q 0r 0s FF pq: X (0h to Fh), rs: Y (0h to Fh)
CAM_AE_Response Direct 8x 01 04 5D pp FF pp: Auto Exposure Response Setting (01h to 30h),
default value: 01h
CAM_VE Off 8x 01 04 3D 03 FF VE Off
VE On 8x 01 04 3D 06 FF VE On
Set Parameter 8x 01 04 2D 00 0q 0r 0s 00 00 00
00 FF
q: Display brightness level (0: Dark to 6: Bright)
r: Brightness compensation selection (0: Very dark, 1: Dark,
2: Standard, 3: Bright)
s: Compensation level (0: Low, 1: Mid, 2: High)
CAM_Defog On 8x 01 04 37 02 0p FF Defog On/Off
p: Defog level (0: mid, 1: low, 2: mid, 3: high)
Off 8x 01 04 37 03 00 FF
