Command List (4/7)
Command Set Command Command Packet Comments
CAM_Aperture Reset 8x 01 04 02 00 FF Aperture Control
Up 8x 01 04 02 02 FF
Down 8x 01 04 02 03 FF
Level 8x 01 04 42 00 00 0p 0q FF pq: Aperture Gain (00h to 0Fh)
Mode 8x 01 05 42 01 0p FF p: Auto (0)/Manual (1) selection
BandWidth 8x 01 05 42 02 0p FF p: Bandwidth setting
0: default (initial value)
1: low bandwidth
2: mid bandwidth
3: wide bandwidth
4: broad bandwidth
Crispening 8x 01 05 42 03 0p FF p: Crispening (0h to 7h)
H/V balance 8x 01 05 42 04 0p FF p: H/V Balance (5h to 9h)
B/W balance 8x 01 05 42 05 0p FF p: B/W Balance (0h to 4h)
Limit 8x 01 05 42 06 0p FF p: Limit (0h to 7h)
HighLightDetail 8x 01 05 42 07 0p FF p: High light detail (0h to 4h)
SuperLow 8x 01 05 42 08 0p FF p: Super low emphasis (0h to 7h)
CAM_HR On 8x 01 04 52 02 FF High Resolusion Mode On/Off
Off 8x 01 04 52 03 FF
CAM_NR Noise Reduction 8x 01 04 53 pp FF p: NR setting (00h: Off, 01h to 05h: level, 7Fh: 2D/3D manual
setting)
2D NR/3D NR 8x 01 05 53 0p 0q FF p: 2D NR level (0h to 5h), q: 3D NR level (0h to 5h)
CAM_Stabilizer On 8x 01 04 34 02 FF Image Stabilizer On/Off
Off 8x 01 04 34 03 FF
CAM_Gamma — 8x 01 04 5B 0p FF p: Gamma Setting (0: Standard, 1: Straight, 2: Pattern)
Pattern 8x 01 05 5B 0p 0q 0r FF pqr: Selection pattern (001h to 200h)
Offset 8x 01 04 1E 00 00 00 0s 0t 0u FF s: Polarity offset (0 is plus, 1 is minus)
tu: Offset s=0 (00h to 40h)
Offset s=1 (00h to 40h)
CAM_HighSensitivity On 8x 01 04 5E 02 FF High Sensitivity mode On/Off
Off 8x 01 04 5E 03 FF
CAM_LR_Reverse On 8x 01 04 61 02 FF LR Reverse On/Off
Off 8x 01 04 61 03 FF
CAM_Freeze On 8x 01 04 62 02 FF Freeze On/Off
Off 8x 01 04 62 03 FF
CAM_PictureEffect Off 8x 01 04 63 00 FF Picture Effect Setting
Black & White 8x 01 04 63 04 FF
CAM_PictureFlip On 8x 01 04 66 02 FF E-Flip On/Off
Off 8x 01 04 66 03 FF
CAM_ICR On 8x 01 04 01 02 FF ICR Mode On/Off
Off 8x 01 04 01 03 FF
CAM_AutoICR On 8x 01 04 51 02 FF Auto ICR Mode On/Off
Off 8x 01 04 51 03 FF
Threshold 8x 01 04 21 00 00 0p 0q FF
pq: ICR On  Off Threshold Level (00h to FFh)
CAM
_AutoICRAlarmReply
On 8x 01 04 31 02 FF Auto ICR switching Alarm On/Off
Off 8x 01 04 31 03 FF
(Reply) y0 07 04 31 02 FF
ICR Off  On
y0 07 04 31 03 FF
ICR On  Off
