FCB-ER8550/CR8550(GB) D-201-100-12(1)
38
Command List (5/7)
Command Set Command Command Packet Comments
CAM_Memory Reset 8x 01 04 3F 00 pp FF pp: Memory Number (=0h to 63h)
Set 8x 01 04 3F 01 pp FF
Recall 8x 01 04 3F 02 pp FF
CAM_Custom Reset 8x 01 04 3F 00 7F FF Starts up in this mode when the power is turned on.
Set 8x 01 04 3F 01 7F FF
Recall 8x 01 04 3F 02 7F FF
CAM_MemSave Write 8x 01 04 23 0X 0p 0q 0r 0s FF X: 00h to 07h (Address), total 16 byte
pqrs: 0000h to FFFFh (Data)
CAM_Display On 8x 01 04 15 02 FF Display On/Off
Off 8x 01 04 15 03 FF
On/Off 8x 01 04 15 10 FF
CAM_MultiLineTitle Title Set1 8x 01 04 73 1L 00 nn pp
qq 00 00 00 00 00 00 FF
L: Line Number, nn: H-position
pp: Color, qq: Blink
Title Set2 8x 01 04 73 2L mm nn pp
qq rr ss tt uu vv ww FF
L: Line Number,
mnpqrstuvw: Setting of characters (1 to 10)
Title Set3 8x 01 04 73 3L mm nn pp
qq rr ss tt uu vv ww FF
L: Line Number,
mnpqrstuvw: Setting of characters (11 to 20)
Title Clear 8x 01 04 74 1p FF Title Setting clear (p: 0h to Ah, F= all lines)
On 8x 01 04 74 2p FF Title display On/Off (p: 0h to Ah, F= all lines)
Off 8x 01 04 74 3p FF
CAM_Mute On 8x 01 04 75 02 FF Muting On/Off
Off 8x 01 04 75 03 FF
On/Off 8x 01 04 75 10 FF
CAM_PrivacyZone SetMask 8x 01 04 76 mm nn
0r 0r 0s 0s FF
mm: Mask Settings
nn 00: Modify, 01: New
rr: W, ss: H
SetMaskTable 8x 01 05 70 0p FF p: Table (0h to 1h)
Display 8x 01 04 77 pp pp pp pp FF Mask Display On/Off
pp pp pp pp: Mask Settings (0: Off, 1: On)
SetMaskColor 8x 01 04 78 pp pp pp pp
qq rr FF
pp pp pp pp: Mask Color Settings
qq: Color Setting when 0 is selected
rr: Color Setting when 1 is selected
SetPanTiltAngle 8x 01 04 79 0p 0p 0p
0q 0q 0q FF
Pan/Tilt Angle Settings
ppp: Pan
qqq: Tilt
SetPTZMask 8x 01 04 7B mm 0p 0p 0p
0q 0q 0q 0r 0r 0r 0r FF
Pan/Tilt/Zoom Settings for Mask
ppp: Pan, qqq: Tilt, rrrr: Zoom, mm: Mask Settings
Non_InterlockMask 8x 01 04 6F mm
0p 0p 0q 0q 0r 0r 0s 0s FF
mm: Non_Interlock Mask Settings
pp: X, qq: Y, rr: W, ss: H
CenterLineOff 8x 01 04 7C 03 FF Center Line Display Off
CenterLineOn 8x 01 04 7C 04 FF Center Line Display On
CAM_IDWrite — 8x 01 04 22 0p 0q 0r 0s FF pqrs: Camera ID (=0000h to FFFFh)
CAM_Continuous
ZoomPosReply
On 8x 01 04 69 02 FF Zoom Position data Continuous Output On/Off
Off 8x 01 04 69 03 FF
(Reply) y0 07 04 69 0p 0p 0q 0q 0q 0q FF pp: D-Zoom Position
* 00: When Zoom Mode is Combine
qqqq: Zoom Position
CAM_ZoomPos
ReplyIntervalTimeSet
— 8x 01 04 6A 00 00 0p 0p FF pp: Interval Time [V cycle]
01h to FFh
CAM_Continuous
FocusPosReply
On 8x 01 04 16 02 FF Focus Position data Continuous Output On/Off
Off 8x 01 04 16 03 FF
(Reply) y0 07 04 16 00 00 0p 0p 0p 0p FF pppp: Focus Position
