Command List (6/7)
Command Set Command Command Packet Comments
CAM_FocusPosReply
IntervalTimeSet
— 8x 01 04 1A 00 00 0p 0p FF pp: Interval Time [V cycle] 01h to FFh
CAM_RegisterValue — 8x 01 04 24 mn 0p 0q FF mn: Register No. (=00h to 7Fh)
pq: Register Value (=00h to FFh)
CAM_ColorEnhance Parameter Set 8x 01 04 20 mm 00 pp 40 40 ss 40 40 FF mm: Threshold level
pp: Y fixed color for high-intensity
ss: Y fixed color for low-intensity
Each parameter setting 00h to 7Fh
On 8x 01 04 50 02 FF Color Enhancement On/Off
Off 8x 01 04 50 03 FF
CAM_ChromaSuppress — 8x 01 04 5F 0p FF p: Chroma Suppress setting level
00: Off
01h to 03h: On (3 levels).
Effect increases as the level number increases.
CAM_ColorGain Direct 8x 01 04 49 00 00 00 0p FF p: Color Gain Setting 0h (60%) to Eh (200%)
CAM_ColorHue Direct 8x 01 04 4F 00 00 00 0p FF p: Color Hue Setting 0h (-14 degrees) to Eh (+14 degrees)
CAM_ExExpComp
(Extended command)
Reset 8x 01 04 1F 0E 00 00 FF Exposure compensation reset
Up 8x 01 04 1F 0E 02 pp FF Exposure compensation up
pp: Step number
pp=00h to 7Fh (However, 00h is the same operation as 01h.)
Down 8x 01 04 1F 0E 03 pp FF Exposure compensation down
pp: Step number
pp=00h to 7Fh (However, 00h is the same operation as 01h.)
Direct 8x 01 04 1F 4E 00 00 0p 0q FF Set the exposure compensation to the specified level
pq: Level
pq=00h to FFh
CAM_ExAperture
(Extended command)
Reset 8x 01 04 1F 02 00 00 FF Aperture control reset
Up 8x 01 04 1F 02 02 pp FF Aperture control up
pp: Step number
pp=00h to 7Fh (However, 00h is the same operation as 01h.)
Down 8x 01 04 1F 02 03 pp FF Aperture control down
pp: Step number
pp=00h to 7Fh (However, 00h is the same operation as 01h.)
Direct 8x 01 04 1F 42 00 00 0p 0q FF Set the aperture control to the specified level
pq: Level
pq=00h to FFh
CAM_ExAutoICR
(Extended command)
Threshold
(ONOFF)
8x 01 04 1F 21 00 00 0p 0q FF pq: ICR ONOFF threshold level when Auto ICR
pq=00h to FFh
On Level 8x 01 04 1F 21 01 00 0r 0s FF pq: ICR OFFON threshold level when Auto ICR
pq=00h to 16h
CAM_ExColorGain
(Extended command)
Direct 8x 01 04 1F 49 00 00 0p 0q FF Color Gain Setting
pq: Gain setting level
pq=00h (0%) to FFh (200%)
CAM_ExColorHue
(Extended command)
Direct 8x 01 04 1F 4F 00 00 0p 0q FF Color Hue Setting
pq: Phase setting level
pq=00h (-14 degrees) to FFh (14 degrees)
CAM_HLC Parameter Set 8x 01 04 14 0p 0q FF p: HLC level (0: Off, 1: On)
q: HLC mask level (0: Off, 1: On)
CAM_ColorBar Off 8x 01 7E 04 7D 00 FF —
On (Color bar 100%
8 colors)
8x 01 7E 04 7D 01 FF
On (Color bar 100%
7 colors)
8x 01 7E 04 7D 02 FF
On (Gray scale) 8x 01 7E 04 7D 03 FF
