Exposure control (3/3)
Iris Gain
Bright
29 F2.0 48 dB
28 F2.0 45 dB
27 F2.0 42 dB
26 F2.0 39 dB
25 F2.0 36 dB
24 F2.0 33 dB
23 F2.0 30 dB
22 F2.0 27 dB
21 F2.0 24 dB
20 F2.0 21 dB
1F F2.0 18 dB
1E F2.0 15 dB
1D F2.0 12 dB
1C F2.0 9 dB
1B F2.0 6 dB
1A F2.0 3 dB
19 F2.0 0 dB
18 F2.2 0 dB
17 F2.4 0 dB
16 F2.6 0 dB
15 F2.8 0 dB
14 F3.1 0 dB
13 F3.4 0 dB
12 F3.7 0 dB
11 F4.0 0 dB
10 F4.4 0 dB
0F F4.8 0 dB
0E F5.2 0 dB
0D F5.6 0 dB
0C F6.2 0 dB
0B F6.8 0 dB
0A F7.3 0 dB
09 F8.0 0 dB
08 F8.7 0 dB
07 F9.6 0 dB
06 F10 0 dB
05 F11 0 dB
00 CLOSE 0 dB
1D to 20 can be set only when the high-sensitivity mode is ON.
Exposure Comp.
0E +7 +10.5 dB
0D +6 +9 dB
0C +5 +7.5 dB
0B +4 +6 dB
0A +3 +4.5 dB
09 +2 +3 dB
08 +1 +1.5 dB
07 0 0 dB
06 −1 −1.5 dB
05 −2 −3 dB
04 −3 −4.5 dB
03 −4 −6 dB
02 −5 −7.5 dB
01 −6 −9 dB
00 −7 −10.5 dB
Zoom Ratio and Zoom Position
(for reference)
Optical Zoom
Ratio
Optical Zoom
Position Data
1× 0000
2× 0DC1
3× 186C
4× 2015
5× 2594
6× 29B7
7× 2CFB
8× 2FB0
9× 320C
10× 342D
11× 3608
12× 37AA
13× 391C
14× 3A66
15× 3B90
16× 3C9C
17× 3D91
18× 3E72
19× 3F40
20×
4000
