Digital Zoom Combine mode
Digital Zoom
Ratio
Digital Zoom
Position Data
1× 4000
2× 6000
3× 6AAB
4× 7000
5× 7334
6× 7556
7× 76DC
8× 7800
9× 78E4
10× 799A
11× 7A2F
12× 7AC0
Digital Zoom Separate mode
Digital Zoom
Ratio
Digital Zoom
Position Data
1× 00
2× 80
3× AA
4× C0
5× CC
6× D5
7× DB
8× E0
9× E3
10× E6
11× E8
12× EB
Lens control
Zoom Position
0000 to 4000 to 7AC0
wide end Optical Digital
tele end tele end
Focus Position
1000 to F000
Far end Near end
Focus Near
Limit
1000: Over Inf
2000: 10 m
3000: 5 m
4000: 3.3 m
5000: 2.5 m
6000: 2 m
7000: 1.7 m
8000: 1.5 m
9000: 1 m
A000: 50 cm
B000: 30 cm
(initial setting)
C000: 15 cm
D000: 6 cm
E000: 1 cm
As the distance on the left
will differ due to temperature
characteristics, etc., use as
approximate values.
* The lower 1 byte is fixed at 00.
wide/tele Limit Setting
wide/tele Limit
Setting Value
wide Limit tele Limit
Zoom
Position
Zoom
Ratio
Zoom
Position
Zoom
Ratio
00
0000 1.00 4000 20.00
10
0170 1.09 3E8F 18.14
20
02E0 1.18 3D1F 16.53
30
0450 1.28 3BAF 15.12
40
05C0 1.38 3A3F 13.89
50
0730 1.47 38CF 12.80
60
08A1 1.58 375E 11.83
70
0A11 1.69 35EE 10.96
80
0B81 1.81 347E 10.18
90
0CF1 1.94 32F7 9.44
A0
0E61 2.07 319E 8.83
B0
0FD1 2.19 302E 8.22
C0
1142 2.32 2EBD 7.65
D0
12B2 2.44 2D4D 7.13
E0
1422 2.58 2BDD 6.66
F0
1592 2.72 2A6D 6.22
FF
16EB 2.85 2914 5.85
