FCB-ER8550/CR8550(GB) D-201-100-12(1)
71
Reset Timing Specification
Low level (GND) pulse (whose width is 10 ms or more) resets this camera.
GND
Treset > 10 ms
Reset by Visca command
The time required from the end of camera reset to the issue of Network Change is as shown below.
HOST CAMERA
CAM_RESET
ACK
BOOT UP SEQUENCE
Maximum: 5 sec
Maximum: 2 sec
Network Change
Address set
