Basic Functions
FCB-EH6300(GB) A-E23-100-13(1)
The maximum value of Defog mode in the low,
mid and high levels can be set respectively.
Extended mode: 5F
On/Off can be set. (initial setting is OFF.)
For details, see page 21.
Note
After changing the register setting turn off the camera, then turn it
on again.
Privacy Zone Masking Settings
For details, see page 16.
Motion detection
For details, see page 19.
Title Display
• You can set a title of up to 11 lines. One line can
contain up to 20 characters.
• You can set display on/off, the horizontal position of
the first character, blinking state and color for each
line.
• The camera gives priority to a title display when the
camera status is displayed on the relevant line. On the
lines where a title is not set, the camera status is
displayed.
Line Number 00h to 0Ah
H-position 00h to 1Fh
Color
00h WHITE
01h YELLOW
02h VIOLET
03h RED
04h CYAN
05h GREEN
06h BLUE
Blink
00h OFF
01h ON
00 01 02 03 04 05 06 07
A B C D E F G H
08 09 0A 0B 0C 0D 0E 0F
I J K L M N O P
10 11 12 13 14 15 16 17
Q R S T U V W X
18 19 1A 1B 1C 1D 1E 1F
Y Z & ? ! 1 2
20 21 22 23 24 25 26 27
3 4 5 6 7 8 9 0
28 29 2A 2B 2C 2D 2E 2F
À È Ì Ò Ù Á É Í
30 31 32 33 34 35 36 37
Ó Ú Â Ê Ô Æ Ã
38 39 3A 3B 3C 3D 3E 3F
Õ Ñ Ç ß Ä Ï Ö Ü
40 41 42 43 44 45 46 47
Å $ ¥ £ ¿ ¡
48 49 4A 4B 4C 4D 4E 4F
ø ” : ’ . , / -
Privacy Zone Masking Function
Privacy Zone masking protects private objects and
areas such as house windows, entrances, and exits
which are within the camera’s range of vision but not
subject to surveillance.
Privacy zone masking can be masked on the monitor to
protect privacy.
Features
• Mask can be set on up to 24 places according to Pan/
Tilt positions.
• Mask can be displayed on 8 places per screen
simultaneously.
• Individual on/off zone masking settings.
• Two colors can be individually set for each of
24 privacy zones.
• Interlocking control with zooming.
• Interlocking control with Pan/Tilt.
• Non-interlocking control with Pan/Tilt.
