Command Set Command Command Packet Comments
CAM_ExpComp On 8x 01 04 3E 02 FF Exposure Compensation On/Off
Off 8x 01 04 3E 03 FF
Reset 8x 01 04 0E 00 FF Exposure Compensation Amount Setting
Up 8x 01 04 0E 02 FF
Down 8x 01 04 0E 03 FF
Direct 8x 01 04 4E 00 00 0p 0q FF pq: ExpComp Position
CAM_BackLight On 8x 01 04 33 02 FF Backlight Compensation On/Off
Off 8x 01 04 33 03 FF
CAM_SpotAE On 8x 01 04 59 02 FF Spot Auto Exposure Setting
Off 8x 01 04 59 03 FF
Position 8x 01 04 29 0p 0q 0r 0s FF pq: X (0h to Fh), rs: Y (0h to Fh)
CAM_AE_Response Direct 8x 01 04 5D pp FF pp: Auto Exposure Response Setting (01h to 30h),
initial setting: 01h
CAM_WD On 8x 01 04 3D 02 FF WD On
Off 8x 01 04 3D 03 FF WD Off
VE On 8x 01 04 3D 06 FF VE On
Set Parameter 8x 01 04 2D 00 0q 0r 0s 00 00 00
00 FF
q: Display brightness level (0: Dark to 6: Bright)
r: Brightness compensation selection (0: Very dark, 1: Dark,
2: Standard, 3: Bright)
s: Compensation level (0: Low, 1: Mid, 2: High)
CAM_Defog
(Supported in FW ver. 2.00 or
earlier)
On 8x 01 04 37 02 00 FF Defog On/Off
Off 8x 01 04 37 03 00 FF
CAM_Defog
(Supported in FW ver. 3.00 or
later)
On 8x 01 04 37 02 0p FF Defog On/Off
p: Defog level (0: mid, 1: low, 2: mid, 3: high)
Off 8x 01 04 37 03 00 FF
CAM_Aperture Reset 8x 01 04 02 00 FF Aperture Control
Up 8x 01 04 02 02 FF
Down 8x 01 04 02 03 FF
Direct 8x 01 04 42 00 00 0p 0q FF pq: Aperture Gain
CAM_HR On 8x 01 04 52 02 FF High Resolution Mode On/Off
Off 8x 01 04 52 03 FF
CAM_NR Noise Reduction 8x 01 04 53 pq FF pq: NR setting
(00: Off, 01 to 05: level 1 to 5, 7F: 2D/3D NR independent
setting available)
2D/3D NR independent
setting (Supported in FW
version 6.00 or later)
8x 01 05 53 0p 0q FF p: 2DNR level (0: Off, 1 to 5: level 1 to 5)
q: 3DNR level (0: Off, 1 to 5: level 1 to 5)
CAM_Gamma — 8x 01 04 5B 0p FF p: Gamma Setting (0: Standard, 1: Straight)
CAM_HighSensitivity On 8x 01 04 5E 02 FF High Sensitivity mode On/Off
Off 8x 01 04 5E 03 FF
CAM_LR_Reverse On 8x 01 04 61 02 FF LR Reverse On/Off
Off 8x 01 04 61 03 FF
CAM_Freeze On 8x 01 04 62 02 FF Freeze On/Off
Off 8x 01 04 62 03 FF
CAM_PictureEffect Off 8x 01 04 63 00 FF Picture Effect Setting
Neg.Art 8x 01 04 63 02 FF
Black & White 8x 01 04 63 04 FF
CAM_MinShutter
(Supported in FW ver. 3.00 or
later)
On 8x 01 04 12 02 FF pq: Minimum Shutter Position (05h to 11h)
Off 8x 01 04 12 03 FF
Limit 8x 01 04 13 00 00 0p 0q FF
