Inquiry Command List (2/4)
Inquiry Command Command Packet Inquiry Packet Comments
CAM_SpotAEModeInq 8x 09 04 59 FF y0 50 02 FF On
y0 50 03 FF
Off
CAM_SpotAEPosInq 8x 09 04 29 FF y0 50 0p 0q 0r 0s FF pq: X Position, rs: Y Position
CAM_WDModeInq 8x 09 04 3D FF y0 50 02 FF On
y0 50 03 FF
Off
y0 50 06 FF VE On
CAM_WDParameterInq 8x 09 04 2D FF y0 50 00 0q 0r 0s 0t 0u 00 00 FF q: Display brightness level (0: Dark to 6: Bright)
r: Brightness compensation selection (0: Very dark,
1: Dark, 2: Standard, 3: Bright)
s: Compensation level (00h: Low, 01h: Mid, 02h: High)
tu: Always 0
CAM_AEResponseInq 8x 09 04 5D FF y0 50 pp FF pp: 01h to 30h
CAM_DefogInq
(Supported in FW ver. 2.00 or earlier)
8x 09 04 37 FF y0 50 02 00 FF Defog On
y0 50 03 00 FF Defog Off
CAM_DefogInq
(Supported in FW ver. 3.00 or later)
8x 09 04 37 FF y0 50 02 0p FF p: Defog level (0: mid, 1: low, 2: mid, 3: high)
y0 50 03 00 FF Defog Off
CAM_ApertureInq 8x 09 04 42 FF y0 50 00 00 0p 0q FF pq: Aperture Gain
CAM_HRModeInq 8x 09 04 52 FF y0 50 02 FF On
y0 50 03 FF
Off
CAM_NRInq 8x 09 04 53 FF y0 50 pq FF pq: NR level
(00: Off, 01 to 05: level 1 to 5, 7F: 2D/3D NR
independent setting available)
CAM_NR2D3Dinq
(Supported in FW version 6.00 or
later)
8x 09 05 53 FF y0 50 0p 0q FF p: 2D NR level (0: Off, 01 to 05: level 1 to 5)
q: 3D NR level (0: Off, 01 to 05: level 1 to 5)
CAM_GammaInq 8x 09 04 5B FF y0 50 0p FF Gamma p: 00h , 01h
CAM_HighSensitivityInq 8x 09 04 5E FF y0 50 02 FF On
y0 50 03 FF
Off
CAM_LR_ReverseModeInq 8x 09 04 61 FF y0 50 02 FF On
y0 50 03 FF
Off
CAM_FreezeModeInq 8x 09 04 62 FF y0 50 02 FF On
y0 50 03 FF
Off
CAM_PictureEffectModeInq 8x 09 04 63 FF y0 50 00 FF Off
y0 50 02 FF
Neg.Art
y0 50 04 FF Black & White
CAM_PictureFlipModeInq 8x 09 04 66 FF y0 50 02 FF On
y0 50 03 FF
Off
CAM_ICRModeInq 8x 09 04 01 FF y0 50 02 FF On
y0 50 03 FF
Off
CAM_AutoICRModeInq 8x 09 04 51 FF y0 50 02 FF On
y0 50 03 FF
Off
CAM_AutoICRThresholdInq 8x 09 04 21 FF y0 50 00 00 0p 0q FF
pq: ICR On  Off Threshold Level
CAM_AutoICRAlarmReplyInq 8x 09 04 31 FF y0 50 02 FF On
y0 50 03 FF
Off
CAM_MemoryInq 8x 09 04 3F FF y0 50 pp FF pp: Memory number recalled last
CAM_MemSaveInq 8x 09 04 23 0X FF y0 50 0p 0q 0r 0s FF X: 00h to 07h (Address)
pqrs: 0000h to FFFFh (Data)
CAM_DisplayModeInq 8x 09 04 15 FF
(8x 09 06 06 FF)
y0 50 02 FF On
y0 50 03 FF
Off
CAM_MuteModeInq 8x 09 04 75 FF y0 50 02 FF On
y0 50 03 FF
Off
