Parts and controls
Figures in ( ) are reference pages.
Speaker
Built-in microphone
Lens (Carl Zeiss lens)
LENS COVER switch (17, 19)
A/V Remote Connector (24, 35)
Power zoom lever (18, 20)
PHOTO button (20)
CHG (charge) lamp (13)
ACCESS lamp (Hard disk) (13)
While the lamp is lit or flashing, the
camcorder is reading or writing data.
Battery pack (13)
BATT (battery) release lever (14)
DC IN jack (13)
“Memory Stick Duo” media slot (39)
(Movie)/ (Photo) lamps (15)
MODE button (19)
START/STOP button (18)
Grip belt (17)
Hook for a shoulder belt
Tripod receptacle (38)
LCD screen/Touch panel (15)
If you rotate the LCD panel 180 degrees, you
can close the LCD panel with the LCD screen
facing out. This is convenient during playback
operations.
(HOME) button* (41)
Zoom buttons* (18, 20)
You can zoom in or out.
START/STOP button* (18)
*DCR-SR48/SR67/SR87
POWER button (15)
DISP (display) button (22)
EASY button (20)
