Sony HCD-SHAKEX1 - IC Information and Parts Lists; IC Pin Function Descriptions

HCD-SHAKEX1/SHAKEX3/SHAKEX7
63
Pin No. Pin Name I/O Description
1SRC-RST0ONot used
2 VIDEO-MUTE O Muting Control for Video
3 CDM-UNLOAD-SW I CDM UNLOAD SW
4 CDM-LOAD-SW I CDM LOAD SW
5 BT-RESET O Reset signal output to Bluetooth section
6 AC Supply Low Det I AC Supply Low voltage Detection
7 Vcc - Power supply terminal (+3.3V)
8 BT-ON O Bluetooth on/off control signal output terminal for bluetooth section
9Vss-Ground terminal
10 TEST-MON10 O Test port for software checking
11 PVcc - Power supply terminal (+3.3V)
12 NFC INT I NFC interrupt
13 MTK-POWER-CTRL O Power Control pin for MTK
14 AUDIO_CLK_OUT O Clock Signal from Aragon to MTK master clock
15 MTK-RESET O MTK Reset pin
16 MTK-BUSY O BUSY Signal communication between MTK
17 MTK-CLK I Clock Signal from MTK
18 Vss - Ground terminal
19 MTK-XIFCS I MTK CHIP SELECT
20 MTK-SDI I Data In Signal from MTK
21 Vcc - Power supply terminal (+3.3V)
22 MTK-SDO O Data Out Signal to MTK
23 Vss - Ground terminal
24 SSI3_BCKO I Bit clock signal from MTK to Aragon
25 PVcc - Power supply terminal (+3.3V)
26 SSI3_LRCKO I LR clock signal from MTK to Aragon
27 C-CONT O Trigger port to start charging of SPM
28 SSI3_DI I SRC from MTK to Aragon data in
29 SSI0_BCKO O Clock signal from Aragon to Wf DAC BCK
30 SSI0_LRCKO O Clock signal from Aragon to Wf DAC LRCK
31 Vss - Ground terminal
32 SSI0_DO O Data Out from Aragon to Wf DAC
33 SSI2_DO O Data out from Aragon to AUX OUT DAC
34 Vcc - Power supply terminal (+3.3V)
35 FL-CLK O Serial clock output to FL CIG
36 Vss - Ground terminal
37 CKIO - Not used
38 TEST-MON38 O Test port for software checking.
39 PVcc - Power supply terminal (+3.3V)
40 FL-SOUT O Serial data output to FL CIG
41 ANALOG-ASEL O Multiplexer selector A for Analog input
42 ANALOG-BSEL O Multiplexer selector B for Analog input
43 DEBUG -TxD O TxD (for Debug)
44 TEST-MON44 O Test port for software checking.
45 POWER-KEY I Power Key input terminal
46 Vss - Ground terminal
47 USB-OC I USB Overcurrent Detection input port
48 RGB-SOUT
O
Serial data output to RGB driver
49 TEST-MON49 O Test port for software checking.
50 PVcc - Power supply terminal (+3.3V)
51 LINK-OUT-B O Selector B for Party Chain Signal
52 VBUS-OE O MTK Vbus Output enable control pin
53 NFC-RF-DET I NFC RF signal detection signal input from the NFC section
54 SSI1_DO O Data Out signal from Aragon to Tw DAC
• IC Pin Function Descriptions
MOTHERBOARD BOARD (8/8) IC101 R7S7200032CFP-A (SYSTEM CONTROL)
Ver. 1.1
