39
<INTERCOM>
19
INTERCOM RECEIVE
SELECT
SEPARATE
, MIX
ENG ---, LEFT
, RIGHT, BOTH
PROD ---, LEFT
, RIGHT, BOTH
PGM1 ---, LEFT, RIGHT
, BOTH
PGM2 ---, LEFT, RIGHT
, BOTH
PGM3 ---
, LEFT, RIGHT, BOTH
TRACKER ---, LEFT
, RIGHT, BOTH
SIDE TONE MUTE, 1 to 99, 50
<TRACKER>
20
TRACKER RECEIVE
SELECT
SEPARATE, MIX
[1-LR]
ENG ---, LEFT
, RIGHT, BOTH
PROD ---, LEFT
, RIGHT, BOTH
PGM1 ---, LEFT, RIGHT
, BOTH
PGM2 ---, LEFT, RIGHT
, BOTH
PGM3 ---
, LEFT, RIGHT, BOTH
[2]
ENG ---, LEFT
, RIGHT, BOTH
PROD ---, LEFT
, RIGHT, BOTH
PGM1 ON, OFF
PGM2 ON, OFF
PGM3 ON, OFF
INPUT LEVEL –20 dBu, 0 dBu
–6 dB, 0 dB, 6 dB
OUTPUT LEVEL L-CH 0 dBu
, –6 dBu, –12 dBu, –18 dBu,
–20 dBu, –24 dBu
OUTPUT LEVEL R-CH
OUTPUT LEVEL 2
<EARPHONE>
21
EARPHONE
RECEIVE SELECT
SEPARATE
, MIX
ENG ---, LEFT
, RIGHT, BOTH
PROD ---, LEFT
, RIGHT, BOTH
PGM1 ---, LEFT, RIGHT
, BOTH
PGM2 ---, LEFT, RIGHT
, BOTH
PGM3 ---
, LEFT, RIGHT, BOTH
TRACKER ---, LEFT
, RIGHT, BOTH
SIDE TONE MUTE, 1 to 99, 50
<OPERATOR FILE>
22
READ (USB t CAM) Execute via ENTER. Reads the operator file from a USB drive.
WRITE (CAM t USB) Execute via ENTER. Writes the current settings of the operator file items
to a USB drive.
PRESET Execute via ENTER. Sets the operator file items to the preset values in
internal memory.
OPERATION
Page title
Page No.
Item Settings Description
