Specifications
HDC3100/3170
Optional Accessories/Related
Equipment
Design and specifications are subject to change without
notice.
General
Power requirements AC 240 V, 1.4 A (max.)
DC 12 V, 9.5 A (max.)
DC 240 V, 1.05 A (max.)
Operating temperature –20°C to +45°C (–4°F to +113°F)
Storage temperature –20°C to +60°C (–4°F to +140°F)
Mass HDC3100: Approx. 4.8 kg (10 lb 9 oz)
HDC3170: Approx. 5.0 kg (11 lb 0.4 oz)
Dimensions See page 55.
Imager
Imager 2/3 inch CMOS sensor with global shutter
Method 3-chip, RGB
Electrical characteristics
Sensitivity F12.0 (at 2000 lx with 89.9% reflectance)
Image S/N 62 dB or higher
Horizontal resolution 1000 TV lines (at center of screen)
5% or higher modulation
Geometric distortion Negligible (not including lens distortion)
Optical system specifications
Spectral system 3-board prism
Built-in filters 1: CLEAR
2: 1/4ND
3: 1/16ND
4: 1/64ND
Input/output connectors
CCU HDC3100: Optical/electrical multi-
connector (1)
HDC3170: Triax connector (1)
LENS 12-pin (1)
VF 20-pin (1)
MIC 1 IN XLR 3-pin, female (1)
AUDIO IN CH1, CH2 XLR 3-pin, female (1 each)
AUDIO switch for MIC: –60 dBu (can be
selected up to –20 dBu in the menu),
balanced
AUDIO switch for LINE: 0 dBu, balanced
INTERCOM XLR 5-pin, female (1)
EARPHONE 4-pole mini jack (1)
(2-polo mono, 3-pole stereo, 4-pole CTIA
standard, 4-pole OMTP standard)
DC IN XLR 4-pin (1), DC 10.5 V to 17 V
DC OUT 4-pin (1), DC 10.5 V to 17 V, max. 0.5 A
(This may be limited by the imposed load or
inputs.)
2-pin (1), DC 10.5 V to 17 V
Max. 2.5 A
(This may be limited by the imposed load or
inputs.)
SDI 1 BNC-type (1)
SDI MONI BNC-type (1)
TEST OUT BNC-type (1)
PROMPTER/
GENLOCK
BNC-type (1)
PROMPTER 1 Vp-p, 75 Ω
GENLOCK HD: SMPTE ST274,
tri-level sync, 0.6 Vp-p,
75 Ω
SD: Black burst
(NTSC: 0.286 Vp-p, 75
Ω
/
PAL: 0.3 Vp-p, 75
Ω
)
RET CTRL 6-pin (1)
REMOTE 8-pin (1)
TRACKER 12-pin (1)
USB USB 2.0 Type A 4-pin (1) (for connecting
USB drive)
Supplied accessories
Before Using This Unit (1)
Operating Instructions (CD-ROM) (1)
Cable clamp belt (1 set)
Screws (+B3×8) (2)
Attached label (1)
Camera number label (1)
Optional accessories
Camera operating
software
HZC-PRV50/PRV50M/PRV50W
HZC-PSF50/PSF50M/PSF50W
HD Electronic
Viewfinder
HDVF-EL20 (0.7-type, color)
HDVF-EL30 (0.7-type, color)
HDVF-EL75 (7.4-type, color)
HDVF-L750 (7-type, color)
HDVF-L770 (7-type, color)
Microphone Holder CAC-12
Return Video Selector CAC-6
Tripod Attachment VCT-14
Low-repulsion
Shoulder Pad
A-8286-346-A
Related equipment
HDCU3100/3170 Camera Control Unit
HDCU2000-series HD Camera Control Unit
RCP-1500/1000 series Remote Control Panel
CNA-1 Camera Control Network Adaptor
