32
Setup Menu
<MENU SETTING>
C14
RESUME ON, OFF Turns ON/OFF the menu mode resume page display
function.
ALARM JUMP ON, OFF
Turns ON/OFF the error-related page display
function for when an error occurs while in menu
mode.
RE DIRECTION CONTROL knob operating mode settings
CATEGORY STD
, RVS STD: CONTROL knob clockwise rotation moves the
CCU MENU pointer (,) down.
RVS: CONTROL knob counterclockwise rotation
moves the CCU MENU pointer (,) down.
PAGE STD
, RVS STD: CONTROL knob clockwise rotation displays
the next page in the menu.
RVS: CONTROL knob counterclockwise rotation
displays the next page in the menu.
ITEM STD
, RVS STD: CONTROL knob clockwise rotation moves the
pointer (,) down to the next item on the page.
RVS: CONTROL knob counterclockwise rotation
moves the pointer (,) down to the next item on the
page.
DATA STD
, RVS STD: CONTROL knob clockwise rotation selects the
next data option.
RVS: CONTROL knob counterclockwise rotation
selects the next data option.
<DISPLAY>
C15
Turn camera messages
and switch settings ON/
OFF for the camera’s
diagnostics screen.
MESSAGE ALL
, WARNING, OFF ALL: Displays all messages.
WARNING: Displays system warning messages and
menu control messages.
OFF: Displays only menu control messages.
MASTER GAIN ON
, OFF Displays or hides the master gain indication.
EVS/SHUTTER ON
, OFF Displays or hides the ECS/shutter indication.
ND FILTER ON
, OFF Displays or hides the ND filter indication.
IRIS ON
, OFF Displays or hides the IRIS indication.
EXTENDER ON
, OFF Displays or hides the EXTENDER indication.
<DATE>
C16
DATE/TIME 20YY/MM/DD hh:mm Sets the date and time.
TIME ZONE hh:mm
–11h59m to +11h59m
Sets the time zone.
<TALLY INPUT>
C17
R-TALLY CONTACT, POWER (24V),
POWER (TTL)
RED tally input setting
G-TALLY CONTACT
, POWER (24V),
POWER (TTL)
GREEN tally input setting
Y-TALLY CONTACT
, POWER (24V),
POWER (TTL)
YELLOW tally input setting
CCU
CONFIGURATION
Page name
Page No.
Item Settings Description
