Setup Menu
NETWORK SETTINGS menu
<OTHERS>
C18
BOARD SELECT DRX1, DRX2, DRX3, DRX4, RC Selects the board to set.
EMBED AUDIO ON
, OFF Sets superimposition of audio data to ON/OFF.
META DATA EMB OFF
, ON Sets superimposition of metadata to ON/OFF.
VIDEO PAYLOAD NEW
, OLD Sets the VIDEO ID.
INTER LOCK OFF
, ON SDI output (3, 4) format linking function
SYNC OUT SD SYNC
, HD SYNC Sets the SYNC OUT connector.
CCU NO 0
, 0 to 96, A to Z Sets the CCU number.
ASSIGNABLE NONE
, BARS, CLEAN, CAM
POWER, FORCE LEGACY, REF
LOCAL HD, REF LOCAL SD
Sets the function for the assignable button.
NONE: No assignment.
BARS: Sets the color bar output to ON/OFF.
CLEAN: Sets character superimposition for all
output slots to ON/OFF.
CAM POWER: Sets camera power to ON/OFF.
FORCE LEGACY: Forces the communication mode
to LEGACY mode.
REF LOCAL HD: Sets GENLOCK to LOCAL HD.
REF LOCAL SD: Sets GENLOCK to LOCAL SD.
CAM MENU OFF
, ON Displays the Camera menu.
• If CAM MENU is set to ON, CCU
CONFIGURATION menu operations cannot be
performed because only Camera menu operations
are available.
• The Camera menu is not displayed when SD
signal is output.
<ALARM SETTING>
C19
FORCE LEGACY OFF, ON
Set to OFF to not display the FORCE LEGACY
alarm.
SUB REF NONE OFF, ON
Set to OFF to not display the REF NONE alarm.
SUB REF INVALID OFF, ON
Sets to OFF to not display the REF INVALID alarm.
NETWORK SETTINGS
Page name
Page No.
Item Settings Description
<IP ADDR SET>
N01
HOST IP ADDRESS 0.0.0.0
to 255.255.255.255 Displays the IP address.
SUB NET MASK 0.0.0.0
to 255.255.255.254 Displays the subnet mask.
DEFAULT GATEWAY 0.0.0.0
to 255.255.255.255 Displays the default gateway.
SET A “SET OK?” message is displayed. Press ENTER
again to confirm the change. (Execute via ENTER.)
