37
<OUTPUT FORMAT1>
S07
SDI-OUT3 Sets the output for the SDI OUT 3 connector.
MONITOR C, M
Sets whether to add characters to the output signal.
C: Characters are not added.
M: Characters are added.
FORMAT FIBER TRANSMIT RATE is HIGH
and SYSTEM is 1.001(525): see
page 54
FIBER TRANSMIT RATE is HIGH
and SYSTEM is 1.000(625): see
page 56
FIBER TRANSMIT RATE is ULTRA
and SYSTEM is 1.001(525): see
page 58
FIBER TRANSMIT RATE is ULTRA
and SYSTEM is 1.000(625): see
page 62
Sets the output signal format of the SDI OUT 3
connector.
OETF SDR
, HDR OETF Sets the gamma curve of the video output.
COLOR BT709, BT2020 Selects the color space of SDI-OUT3 video output.
BT709: Sets the color output format to BT709.
BT2020: Sets the color output format to BT2020.
SDI-OUT4 Sets the output for the SDI OUT 4 connector.
MONITOR C, M
Sets whether to add characters to the output signal.
C: Characters are not added.
M: Characters are added.
When this is set to C (characters are not added), the
CCU MENU will not be displayed. To display it, hold
the DISP/MENU lever in the MENU position for 3
seconds.
FORMAT FIBER TRANSMIT RATE is HIGH
and SYSTEM is 1.001(525): see
page 54
FIBER TRANSMIT RATE is HIGH
and SYSTEM is 1.000(625): see
page 56
FIBER TRANSMIT RATE is ULTRA
and SYSTEM is 1.001(525): see
page 58
FIBER TRANSMIT RATE is ULTRA
and SYSTEM is 1.000(625): see
page 62
Sets the output signal format of the SDI OUT 4
connector.
OETF SDR
, HDR OETF Sets the gamma curve of the video output.
COLOR BT709, BT2020 Selects the color space of SDI-OUT4 video output.
BT709: Sets the color output format to BT709.
BT2020: Sets the color output format to BT2020.
SYSTEM CONFIG
Page name
Page No.
Item Set value Description
