Return format (when FIBER TRANSMIT RATE is set to HIGH and SYSTEM is set to 1.001(525))
UHD-SDI A and UHD-SDI B are dedicated output connectors, and a return format cannot be configured.
*1 720 input can be selected when CCU VIDEO CONVERT is set to ENABLE.
Note
CAMERA
FORMAT
SYSTEM CONFIG t
<RETURN FORMAT3>
SYSTEM CONFIG t
<RETURN FORMAT1>
SYSTEM CONFIG t
<RETURN FORMAT2>
SYSTEM CONFIG t
<RETURN FORMAT IP>
UHD-SDI C, UHD-SDI D SDI-RET1, SDI-RET2,
SDI-RET3, SDI-RET4
SDI-I/O1, SDI-I/O2,
SDI-I/O3, SDI-I/O4
IP-RET1, IP-RET2,
IP-RET3, IP-RET4
UHD/59.94P
(4K/HDR)
3840×2160/59.94P/12G 1080/59.94P/3G
1080/59.94I(PsF)
720/59.94P
*1
525/59.94I(PsF)
1080/59.94P/3G
1080/59.94I(PsF)
720/59.94P
*1
525/59.94I(PsF)
3840×2160/59.94P/12G
(IP-RET4 only)
1080/59.94P/3G (IP-RET1,
IP-RET2 only)
1080/59.94I (IP-RET1,
IP-RET2, IP-RET3 only)
1080/59.94P
(4K/HDR)
3840×2160/59.94P/12G 1080/59.94P/3G
1080/59.94I(PsF)
720/59.94P
*1
525/59.94I(PsF)
1080/59.94P/3G
1080/59.94I(PsF)
720/59.94P
*1
525/59.94I(PsF)
3840×2160/59.94P/12G
(IP-RET4 only)
1080/59.94P/3G (IP-RET1,
IP-RET2 only)
1080/59.94I (IP-RET1,
IP-RET2, IP-RET3 only)
1080/59.94P – 1080/59.94P/3G
1080/59.94I(PsF)
720/59.94P
*1
525/59.94I(PsF)
1080/59.94P/3G
1080/59.94I(PsF)
720/59.94P
*1
525/59.94I(PsF)
1080/59.94P/3G (IP-RET1,
IP-RET2 only)
1080/59.94I (IP-RET1,
IP-RET2, IP-RET3 only)
1080/59.94I – 1080/59.94I(PsF)
525/59.94I(PsF)
1080/59.94I(PsF)
525/59.94I(PsF)
1080/59.94I (IP-RET1,
IP-RET2, IP-RET3 only)
1080/29.97PsF – 1080/59.94I(PsF)
525/59.94I(PsF)
1080/59.94I(PsF)
525/59.94I(PsF)
–
1080/23.98PsF – 1080/59.94I(PsF)
1080/23.98PsF
525/59.94I(PsF)
1080/59.94I(PsF)
1080/23.98PsF
525/59.94I(PsF)
–
720/59.94P – 720/59.94P
525/59.94I(PsF)
720/59.94P
525/59.94I(PsF)
–
1080/
59.94I(RGB444)
–
1080/59.94I(PsF)/RGB444/3G
1080/59.94I(PsF)
525/59.94I(PsF)
1080/59.94I(PsF)/RGB444/3G
1080/59.94I(PsF)
525/59.94I(PsF)
1080/59.94I (IP-RET1,
IP-RET2, IP-RET3 only)
1080/
29.97PsF(RGB444)
– 1080/59.94I(PsF)/RGB444/3G
1080/59.94I(PsF)
525/59.94I(PsF)
1080/59.94I(PsF)/RGB444/3G
1080/59.94I(PsF)
525/59.94I(PsF)
–
1080/
23.98PsF(RGB444)
– 1080/23.98PsF/RGB444/3G
1080/59.94I(PsF)
1080/23.98PsF
525/59.94I(PsF)
1080/23.98PsF/RGB444/3G
1080/59.94I(PsF)
1080/23.98PsF
525/59.94I(PsF)
–
1080/59.94I(2×) – 1080/59.94I(PsF)
525/59.94I(PsF)
1080/59.94I(PsF)
525/59.94I(PsF)
–
720/59.94P(2×) – 720/59.94P
525/59.94I(PsF)
720/59.94P
525/59.94I(PsF)
–
