61
*1 Configurable only on HDCU5000 when HKCU-SDI50 is installed.
*2 Configurable only when the HKCU-SFP50 is installed.
*3 720 output can be selected when CCU VIDEO CONVERT is set to ENABLE.
*4 720 output can be selected when both CCU VIDEO CONVERT is set to ENABLE and the HDR mode of the connected camera is set to OFF.
1080/59.94P(8×)
(HDR/SDR)
1080/59.94P(8×)/3G-A
1080/59.94P(8×)/3G-B
1080/59.94P(8×)/12G
1080/59.94I(8×)
1080/59.94I(8×)/3G-B
1080/59.94I(8×)/12G
720/59.94P(8×)
*4
720/59.94P(8×)/3G-B
*4
720/59.94P(8×)/12G
1080/59.94P(8×)/3G-A
1080/59.94P(8×)/3G-B
720/59.94P(8×)
*4
720/59.94P(8×)/3G-B
*4
(The 4 formats above for
SDI-OUT1, SDI-OUT2 only)
1080/59.94I
1080/59.94P/3G-A
1080/59.94P/3G-B
720/59.94P
*4
525/59.94I
HFR output (1080/59.94) is
linked to SDI-OUT1,
SDI-OUT2, SDI-I/O1, and
SDI-I/O2.
1080/59.94P(8×)/3G-A
1080/59.94P(8×)/3G-B
720/59.94P(8×)
*4
720/59.94P(8×)/3G-B
*4
(The 4 formats above for
SDI-I/O1, SDI-I/O2 only)
1080/59.94I
1080/59.94P/3G-A
1080/59.94P/3G-B
720/59.94P
*4
525/59.94I
HFR output (1080/59.94) is
linked to SDI-OUT1,
SDI-OUT2, SDI-I/O1, and
SDI-I/O2.
–
CAMERA
FORMAT
SYSTEM CONFIG t
<OUTPUT FORMAT3>
or
SYSTEM CONFIG t
<OUTPUT FORMAT4>
SYSTEM CONFIG t
<OUTPUT FORMAT1>
SYSTEM CONFIG t
<OUTPUT FORMAT2>
SYSTEM CONFIG t
<OUTPUT FORMAT IP>
<OUTPUT FORMAT3>:
UHD-SDI A, UHD-SDI B,
UHD-SDI C, UHD-SDI D
<OUTPUT FORMAT4>:
UHD-SDI E
*1
, UHD-SDI F
*1
,
UHD-SDI G
*1
, UHD-SDI H
*1
SDI-OUT1, SDI-OUT2,
SDI-OUT3, SDI-OUT4
SDI-I/O1, SDI-I/O2,
SDI-I/O3, SDI-I/O4
IP-OUT1
*2
, IP-OUT2
*2
,
IP-OUT3
*2
, IP-OUT4
*2
Note
Note
