70
<FRONT INTERCOM>
A04
MIC/PGM (PGM ON), (MIC OFF), (MIC ON) Front panel MIC/PGM switch position (Display only)
I/F (PROD), (ENG), (PRIVATE) Front panel INTERCOM switch position. (Display
only)
PRIVATE SW ENABLE
,
DISABLE(SET TO ENG),
DISABLE(SET TO PROD)
Operation when the INTERCOM switch on the front
panel is set to the PRIV (private) position.
ENABLE: Private operation
DISABLE(SET TO ENG): ENG line operation
INTERCOM MIC DYNAMIC
, ECM, CARBON Sets the headset microphone connected to the
INTERCOM connector on the front panel.
CARBON: Carbon microphone (power supply, 20 dB
gain)
ECM: Electret condenser microphone (power supply,
40 dB gain)
DYNAMIC: Dynamic microphone (no power supply,
60 dB gain)
INTERCOM MIC
TYPE
BALANCED, UNBALANCED
Sets the headset microphone connected to the
INTERCOM connector on the front panel.
BALANCED: Balanced microphone
UNBALANCED: Unbalanced microphone
INTERCOM MIC
GAIN
–6, 0
, +6 dB Sets the microphone input gain.
SIDE TONE LEVEL 0 to 99 50
Sets the side tone level.
PGM MIX MODE OFF
, INCOM+PGM,
L-INCOM/R-PGM
OFF: Signals are not mixed.
INCOM+PGM: INCOM and PGM signals are mixed.
L-INCOM/R-PGM: Outputs INCOM signal through
the left channel and PGM signal through the right.
PGM SELECT PGM1
, PGM2, PGM3,
PGM1+PGM2+PGM3
Selects the PGM audio output from the FRONT
INTERCOM connector.
PGM1 LEVEL 0 to 99, 50
Sets the MIX level of PGM1.
PGM2 LEVEL 0 to 99, 50
Sets the MIX level of PGM2.
PGM3 LEVEL 0 to 99, 50
Sets the MIX level of PGM3.
<TEST TONE>
A05
SOURCE 1kHz Sets the audio source of the test tone.
LEVEL 0, –10, –20
, –30, –40, –50, –60,
–70 [dB]
Sets the level of the test tone.
ANALOG OUT CH NONE
, ALL, MIC1, MIC2,
AES/EBU1, AES/EBU2,
INTERCOM ENG, INTERCOM
PROD
Sets the analog output channel of the test tone.
IP OUT CH NONE
, ALL, MIC1, MIC2,
AES/EBU1, AES/EBU2,
INTERCOM ENG, INTERCOM
PROD
Sets the IP output channel of the test tone.
AUDIO/INTERCOM
Page name
Page No.
Item Set value Description
