Sony HT-1750DP - Specifications

44
US
HT-1750DP 4-244-184-31(1) US
Sensitivity: –
Impedance: 75 ohms
S/N: 100 dB
(A, 20 kHz LPF)
Sensitivity: –
Impedance: –
S/N: 100 dB
(A, 20 kHz LPF)
Specifications
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL
HARMONIC DISTORTION:
With 8 ohm loads, both channels driven, from
40 – 20,000 Hz; rated 90 watts per channel
minimum RMS power, with no more than
0.7 % total harmonic distortion from 250
milliwatts to rated output.
Amplifier section
POWER OUTPUT
Rated Power Output at Stereo Mode
(8 ohms 40 Hz – 20 kHz, THD 0.7 %)
STR-K750P: 90 W + 90 W
Reference Power Output
(8 ohms 1 kHz, THD 0.7 %)
STR-K750P: FRONT
1)
:100 W/ch
CENTER
1)
: 100 W
SURR
1)
: 100 W/ch
1) Depending on the sound field settings and the
source, there may be no sound output.
Frequency response
CD, MD/TAPE, DVD,
VIDEO 1, 2
Inputs (Analog)
CD, MD/TAPE, DVD,
VIDEO 1, 2
2) INPUT SHORT (with sound field and tone
bypassed).
3) Weighted network, input level.
Inputs (Digital)
DVD (Coaxial)
VIDEO 2 (Optical)
Outputs
MD/TAPE (OUT),
VIDEO 1
(AUDIO OUT)
SUB WOOFER
Tone
Gain levels: ±6 dB, 1 dB step
FM tuner section
Tuning range 87.5 - 108.0 MHz
Antenna terminals 75 ohms, unbalanced
Intermediate Frequency
10.7 MHz
Sensitivity
Mono: 18.3 dBf, 2.2 µV/75 ohms
Stereo: 38.3 dBf, 22.5 µV/75 ohms
Usable sensitivity 11.2 dBf, 1 µV/75 ohms
S/N
Mono: 76 dB
Stereo: 70 dB
Harmonic distortion at 1 kHz
Mono: 0.3%
Stereo: 0.5%
Separation 45 dB at 1 kHz
Frequency response 30 Hz – 15 kHz,
+0.5/–2 dB
Selectivity 60 dB at 400 kHz
10 Hz – 50 kHz
+0.5/–2 dB (with sound
field and tone bypassed)
Sensitivity: 500 mV
Impedance: 50 kilohms
S/N
2)
: 96 dB
(A, 500 mV
3)
)
Voltage: 500 mV
Impedance: 10 kilohms
Voltage: 2 V
Impedance: 1 kilohms
