General
Power requirements
120 V AC, 60 Hz
Power consumption
On: 34 W
Standby mode (Control for HDMI is set to on): 0.5 W or less
Standby mode (Control for HDMI is set to off): 0.3 W or less
BLUETOOTH Standby mode: 0.5 W or less
Dimensions (approx.) (w/h/d)
SA-CT370:
900 mm × 50 mm × 113 mm (35 1/2 in × 2 in × 4 1/2 in)
(without wall mounting brackets)
900 mm × 113 mm × 72 mm (35 1/2 in × 4 1/2 in × 2 7/8 in)
(with wall mounting brackets)
SA-CT770:
1030 mm × 50 mm × 113 mm (40 5/8 in × 2 in × 4 1/2 in)
(without wall mounting brackets)
1030 mm × 113 mm × 72 mm (40 5/8 in × 4 1/2 in × 2 7/8 in)
(with wall mounting brackets)
Mass (approx.)
SA-CT370: 2.4 kg (5 Ib 4 5/8 oz)
SA-CT770: 2.6 kg (5 Ib 11 3/4 oz)
POWER OUTPUT (reference)
SA-WCT370: 100 W (per channel at 4 ohms, 100 Hz)
SA-WCT770: 120 W (per channel at 4 ohms, 100 Hz)
Speaker system
Subwoofer system, Bass reflex
Speaker
SA-WCT370: 100 mm × 150 mm (4 in × 6 in) cone type
SA-WCT770: 160 mm (6 3/8 in) cone type
Rated impedance
4 ohms
Power requirements
120 V AC, 60 Hz
Power consumption
On: 30 W
Standby mode: 0.5 W or less
Dimensions (approx.) (w/h/d)
SA-WCT370: 135 mm × 361.5 mm × 394 mm
(5 3/8 in × 14 1/4 in × 15 5/8 in) (vertical)
361.5 mm × 135 mm × 394 mm
(14 1/4 in × 5 3/8 in × 15 5/8 in) (horizontal)
SA-WCT770: 271 mm × 404 mm × 271 mm
(10 3/4 in × 16 in × 10 3/4 in)
Mass (approx.)
SA-WCT370: 7.0 kg (15 Ib 6 7/8 oz)
SA-WCT770: 8.8 kg (17 Ib 10 1/2 oz)
Speaker system
Wireless Sound Specification version 2.0
Frequency band
2.4 GHz (2.4000 GHz - 2.4835 GHz)
Modulation method
Pi / 4 DQPSK
Digital audio input formats supported by the system
* It is possible to input these formats only with HDMI connection.
Subwoofer (SA-WCT370, SA-WCT770)
Wireless transmitter/receiver section
Dolby Digital DTS-HD Master Audio*
Dolby Digital Plus* DTS-HD High Resolution Audio*
Dolby TrueHD* DTS-HD Low Bit Rate*
DTS Linear PCM 2ch 48 kHz or less
DTS 96/24 Linear PCM Maximum 7.1ch 192 kHz or less*
