Useful functions
2 Prepare screws (not supplied) that are suitable for the holes
on the back of the wall mounting brackets.
3 Fasten the screws to two studs in the wall.
The screws should protrude 6 to 7 mm (approx. 1/4 in).
4 Hang the wall mounting brackets fixed on the Bar Speaker on
the screws.
Align the holes in the wall mounting brackets with the screws,
then hang the Bar Speaker on the two screws.
Tip
The Bar Speaker automatically detects whether it is mounted on a wall or
positioned flat, and it optimizes the sound for its orientation.
Hole on the wall mounting bracket
4 mm (3/16 in)
More than 25 mm (1 in)
4.4 mm
(3/16 in)
9.8 mm
(13/32 in)
6 to 7 mm
(approx.
1/4 in)
HT-CT370: 652 mm (25 7/10 in)
HT-CT770: 605 mm (23 17/20 in)
