34
US
POWER OUTPUT (reference)
150 W (at 2.5 ohms, 100 Hz)
Speaker system
Subwoofer speaker system, Bass
reflex
Speaker
160 mm (6 1/2 in) cone type
Power requirements
120 V AC, 60 Hz
Power consumption
On: 25 W
Standby mode: 0.5 W or less
Dimensions* (approx.) (w/h/d)
190 mm × 382 mm × 390 mm (7 1/2 in ×
15 1/8 in × 15 3/8 in)
* Not including projection portion
Mass (approx.)
7.8 kg (17 lb 3 1/5 oz)
Frequency band
2.4 GHz (2.4000 GHz - 2.4835 GHz)
Modulation method
FHSS (Freq Hopping Spread Spectrum)
Design and specifications are subject to
change without notice.
Supported Input Audio
Formats (TV Input)
Audio formats supported by the Sound
Bar are as follows.
•Dolby Digital
•Linear PCM 2ch
Subwoofer (SA-WSD35)
Wireless Transmitter/
Receiver Section
To Next Page
