Sony ICP-X7000

28
Specifications
Accessories supplied
AC adaptor (Max.4)
2)
Track ball (1)
3)
Panel cover (2)
Connecting Screws (4)
Operation Manual (1)
1) Varies depending on the type of module installed.
2) The number depends on the system configuration.
3) Only when attaching the MKS-X7031TB.
Accessories not supplied
AC power cord for AC adaptor
for USA and Canada: 125 V 7 A (2.0 m
(6 ft 7 in)) 1-846-101-21
for Europe: 250 V 2.5 A (2.0 m (6 ft
7 in)) 1-575-131-83
MKS-X7701 Tally/GPI Output Board
Power requirements
12 V DC
Power consumption
7 W
Operation guaranteed temperature
5 ºC to 40 ºC (41 ºF to 104 ºF)
Performance guaranteed temperature
10 ºC to 35 ºC (50 ºF to 95 ºF)
Storage temperature
−20 ºC to +60 ºC (−4ºF to +140ºF)
Dimensions (w/h/d, excluding projections)
296 × 20 × 123 mm
(11
3
/
4
×
13
/
16
× 4
7
/
8
inches)
Mass Approx. 0.5 kg (1 lb 1.6 oz)
TALLY/GPI D-Sub 37-pin (3), female, Relay contact
outputs: 18 × 3
MKS-X7702 Serial Interface Board
Power requirements
12 V DC
Power consumption
1 W
Operation guaranteed temperature
5 ºC to 40 ºC (41 ºF to 104 ºF)
Performance guaranteed temperature
10 ºC to 35 ºC (50 ºF to 95 ºF)
Storage temperature
−20 ºC to +60 ºC (−4ºF to +140ºF)
Dimensions (w/h/d, excluding projections)
296 × 20 × 123 mm
(11
3
/
4
×
13
/
16
× 4
7
/
8
inches)
Mass Approx. 0.3 kg (11 oz)
REMOTE D-Sub 9-pin (6), female, RS-422A
standard, Data transfer rate: 38.4 kbps
If the unit is suddenly taken from a cold to a warm location,
or if ambient temperature suddenly rises, moisture may
form on the outer surface of the unit and/or inside of the
unit. This is known as condensation. If condensation
occurs, turn off the unit and wait until the condensation
clears before operating the unit. Operating the unit while
condensation is present may damage the unit.
(For ICP-X7000/MKS-X7017/MKS-X7018/
MKS-X7019/MKS-X7020/MKS-X7021/MKS-X7023/
MKS-X7026/MKS-X7031TB/MKS-X7032/
MKS-X7035/MKS-X7075)
Due to the characteristics of the material used in the OLED
panel, permanent burn-in or reduction in brightness may
occur.
These problems are not a malfunction.
(For ICP-X7000/MKS-X7011/MKS-X7017/
MKS-X7018/MKS-X7019/MKS-X7024/MKS-X7033/
MKS-X7075)
The LCD panel fitted to this unit is manufactured with high
precision technology, giving a functioning pixel ratio of at
least 99.99%. Thus a very small proportion of pixels may
be “stuck”, either always off (black), always on (red,
green, or blue), or flashing. In addition, over a long period
of use, because of the physical characteristics of the liquid
crystal display, such “stuck” pixels may appear
spontaneously. These problems are not a malfunction.
(For MKS-X7011)
The battery is consumable part that will need periodic
replacement.
When operating at room temperature, a normal
replacement cycle will be about 4 years.
However, this replacement cycle represents only a general
guideline and does not imply that the life expectancy of
these parts is guaranteed. For details on parts replacement,
contact your dealer.
