Sony ILCE-9 - Specifications

ILCE-9
2
Model information table
Model ILCE-9
Destination US, CND, E, KR AEP, UK, RU, E, IND, CH, JE
Color system
NTSC PAL
Lens
––
• Abbreviation
CH : Chinese model
CND : Canadian model
IND : Indian model
JE : Tourist model
KR : Korea model
RU : Russian model
SPECIFICATIONS
Camera
[System]
Camera Type
Interchangeable Lens Digital Camera
Lens
Sony E-mount lens
[Image sensor]
Image format
35mm full frame (35.6mm ×
23.8mm), CMOS image sensor
Effective pixel number of camera
Approx. 24200000 pixels
Total pixel number of camera
Approx. 28300000 pixels
[SteadyShot]
System
In-camera sensor shift image
stabilization system
[Anti-Dust]
System
Charge protection coating on
optical filter and image sensor shift
mechanism
[Auto focus system]
Detection system
Phase detection system/Contrast
detection system
Sensitivity Range
–3EV to +20EV (at ISO 100
equivalent, F2.0)
AF illuminator
Approx. 0.3m to 3m (0.99ft.
to 9.8ft.) (When using an
FE 28-70 mm F3.5-5.6 OSS)
[Electronic viewfinder]
Type
Electronic viewfinder
Total number of dots
3686400dots
Frame coverage
100%
Magnification
Approx. 0.78× with 50mm lens at
infinity, –1m
–1
Eye Point
Approx. 23mm from the eyepiece
and approx. 18.5mm from the
eyepiece frame at –1m
–1
(CIPA
standard compliant)
Diopter Adjustment
–4.0m
–1
to +3.0m
–1
[Monitor]
LCD monitor
7.5cm (3.0 type) TFT drive, touch
panel
Total number of dots
1440000 dots
[Exposure control]
Metering method
1200-zone evaluative metering
Metering Range
–3EV to +20EV (at ISO 100 equivalent
with F2.0 lens)
Flash sync speed
1/250second (when using a flash
manufactured by Sony)
[Continuous shooting]
Continuous shooting speed
(when shooting with the electronic
shutter)
: Maximum of approx.20images
per second/
: Maximum of
approx.10images per second/
:
Maximum of approx.5images per
second
• Based on our measurement
conditions. The speed of
continuous shooting can be
slower, depending on the shooting
conditions.
[Recording format]
File format
JPEG (DCF Ver. 2.0, Exif Ver. 2.31, MPF
Baseline) compliant, RAW (Sony ARW
2.3 format)
Movie (XAVC S format)
MPEG-4 AVC/H.264 XAVC S ver.1.0
format compliant
Video: MPEG-4 AVC/H.264
Audio: LPCM 2ch (48kHz 16bit)
Movie (AVCHD format)
AVCHD format Ver. 2.0 compatible
Video: MPEG-4 AVC/H.264
Audio: Dolby Digital 2ch, equipped
with Dolby Digital Stereo Creator
• Manufactured under license from
Dolby Laboratories.
Movie (MP4 format)
Video: MPEG-4 AVC/H.264
Audio: MPEG-4 AAC-LC 2ch
[Recording media]
Memory Stick media, SD cards
[Slot]
SLOT 1
Slot for SD cards (UHS-I and UHS-II
compatible)
SLOT 2
Multi-slot for Memory Stick PRO Duo
media and SD cards (UHS-I
compatible)
Supports operations between two
memory cards.
[Input/output terminals]
Multi/Micro USB Terminal*
Hi-Speed USB (USB 2.0)
* Supports Micro USB compatible
devices.
HDMI
HDMI type D micro jack
¯ (Microphone) terminal
3.5mm Stereo mini jack
 (Headphones) terminal
3.5mm Stereo mini jack
LAN terminal
(Flash sync) terminal
[Power, general]
Battery pack
Rechargeable battery pack NP-FZ100
Power consumption (while shooting)
Using an FE 28-70 mm F3.5-5.6 OSS
When using the viewfinder:
Approx. 4.1W
When using the monitor:
Approx. 3.0W
[Others]
Microphone
Stereo
Speaker
Monaural
Exif Print
Compatible
DPOF
Compatible
PRINT Image Matching III
Compatible
Dimensions
Approx. 126.9mm × 95.6mm ×
63.0mm
(Approx. 5inches × 37/8inches ×
21/2inches) (W/H/D, excluding
protrusions)
Mass
Approx. 673g (1lb 7.7oz) (including
battery pack and SD card)
Approx. 588g (1lb 4.7oz) (body only)
Operating temperature
0°C to 40°C (32°F to 104°F)
Storage temperature
–20°C to +60°C (–4°F to +140°F)
[Wireless LAN]
Supported format
IEEE802.11b/g/n
Frequency band
2.4GHz
Security
WEP/WPA-PSK/WPA2-PSK
Connection method
Wi-Fi Protected Setup™ (WPS)/
Manual
Access method
Infrastructure mode
[NFC]
Tag type
NFC Forum Type 3 Tag compliant
[Bluetooth communications]
Bluetooth standard Ver. 4.1
Frequency band
2.4GHz
Model No. WW361847
Battery charger BC-QZ1
Input rating
AC 100V to 240V, 50Hz/60Hz,
0.38A
Output rating
DC 8.4V, 1.6A
AC Adaptor AC-UUD12/AC-UUE12
Power requirements
AC 100V to 240V, 50Hz/60Hz, 0.2A
Output voltage
DC 5V, 1.5A
Rechargeable battery pack
NP-FZ100
Nominal voltage
DC 7.2V
Design and specifications are subject
to change without notice.
Still images
(
when shooting with the
mechanical shutter): 1/8000second
to 30seconds, BULB
Movies: 1/8000second to 1/4second
(1/3EV step)
–108060i-compatible devices:
up to 1/60second in AUTO mode
(up to 1/30second in Auto slow
shutter mode)
–108050i-compatible devices:
up to 1/50second in AUTO mode
(up to 1/25second in Auto slow
shutter mode)
ISO sensitivity (Recommended
exposure index)
Still images: ISO 100 to ISO 51200
(Extended ISO: Minimum ISO 50,
maximum ISO 204800), [ISO AUTO]
(ISO 100 to ISO 6400, Maximum/
Minimum can be set.)
Movies: ISO 100 to ISO 51200
equivalent (Extended ISO: Minimum
ISO 100, maximum ISO 102400),
[ISO AUTO] (ISO 100 to ISO 6400
equivalent, Maximum/Minimum can
be set.)
Exposure compensation
±5.0EV (switchable between 1/3EV
and 1/2EV steps)
When using exposure compensation
dial: ±3.0 EV (1/3 EV step)
[Shutter]
Type
Electronically-controlled, vertical-
traverse, focal-plane type
Speed range
Still images (when shooting with the
electronic shutter): 1/32000 second*
to 30seconds (up to 1/8second in
continuous shooting)
* Available only in the M(Manual
Exposure) and S(Shutter Priority)
modes. For details, refer to the
SYSSET
