1-4 (E)
HKJ-101
8. Install the supplied rear panel for J-H3 using the six
M3 case stopper screws .
n
Tighten the screws in the state that the two dowels are
aligned with the holes (a) and (b) on the rear panel as
shown in the figure.
Hole (b)
Hole (a)
Dowel
Dowel
M3 case stopper
screws
M3 case stopper
screws
M3 case stopper
screws
J-H3 rear panel
(Supplied accessory)
