Sony KD-43X7 G Series User Manual

< Application >
Withdrawal of FFC using Non
-ZIF (IPEX connector)
< Connector
location >
Main board side
< Method >
See as follows
< Caution >
See as follows
1-8. FFC REPLACEMENT CAUTION
Initial condition
Step 2
1
1
2
Step 1
1
1
PRESS
PRESS
PULL
2
Press the release lock button downward at same time
(highlighted in red).
Pull FFC in straight direction while pressing
both release lock button at the same time.
1
Note: FFC as in image is only for reference purpose. Actual FFC outlook
may vary by each vendor.
10
SYSSET
2019/05/0102:23:15(GMT+09:00)
