Sony KD-43X80K Dismantling Guide

12
3. Unhook corner hook.
①
Releasing the corner hook by pulling the Rear Cover corner and
insert a jig or ruler.
②
Ensure the jig or ruler is pulled backward.
③
DO NOT pivot on bezel when inserting the jig or ruler.
REAR COVER
Backward
OK
Do NOT pivot on bezel
NG
Bottom Hook Position
321
Ruler or jig to release corner hook
*Wrap ruler with tape to prevent scratch
62mm
306mm
113mm
DISASSEMBLY AND REMOVAL CAUTION 43”

Sony KD-43X80K Specifications

General

Screen Size	43 inches
Display Type	LCD
Smart TV	Yes
Operating System	Google TV
HDMI Ports	4
USB Ports	2
Wi-Fi	Yes
Bluetooth	Yes
Refresh Rate	60 Hz
Processor	4K HDR Processor X1
Audio Output	20 W
Resolution	3840 x 2160
HDR	HDR10, HLG
Weight	9.8 kg (without stand)
