12
Total hooks (top row): 4 hooks
REAR COVER
6. Unhook top row.
① Tilt the rear cover and push upwards on the left and right side.
② Pull the rear cover below the side jack to remove the upper hook.
Hook positioning.
1
2
3
SECTION 1: KD-43X8*K
TOOLS & EQUIPMENTS FFC PRECAUTIONS SECTION 1 SECTION 2 SECTION 3 SECTION 4 SECTION 5 SMART CORE APPENDIX
1-1. DISASSEMBLY AND REMOVAL CAUTION
