Sony KD-43X80K User Manual

CONNECTOR
20
1-4. EXPLODED VIEW AND PART LIST
SECTION 1: KD-43X8*K
REF.
NO
PART NO. DESCRIPTION REMARKS
1
1-010-989-12
CONNECTOR ASSY 4P (SP)
CN3550(BM5A)/CN6600(BM5STY)/
CN6603 (BM5ST)-SP(1)
2
1-010-993-11
FLEXIBLE FLAT CABLE 25P
CN1200(BM5A)-CN102(HT2)(1)
3
1-010-991-11
FLEXIBLE FLAT CABLE 20P
CN3801(BM5A)-J1(WIFI/BT)(1)
4
1-010-995-12
FLEXIBLE FLAT CABLE 51P
CN4200(BM5A)-U1(TCON)(1)
5
1-010-990-11
CONNECTOR ASSY 30P
CN1701(BM5A)-CN6401(GL)(1)
TOOLS & EQUIPMENTS FFC PRECAUTIONS SECTION 1 SECTION 2 SECTION 3 SECTION 4 SECTION 5 SMART CORE APPENDIX
1
2
3
4
5
SYSSET
2022/02/2522:04:10(GMT+09:00)

Sony KD-43X80K Specifications

General

Screen Size	43 inches
Display Type	LCD
Smart TV	Yes
Operating System	Google TV
HDMI Ports	4
USB Ports	2
Wi-Fi	Yes
Bluetooth	Yes
Refresh Rate	60 Hz
Processor	4K HDR Processor X1
Audio Output	20 W
Resolution	3840 x 2160
HDR	HDR10, HLG
Weight	9.8 kg (without stand)
