Sony KD-43X80K User Manual

71
3. Unhook corner hook.
① Releasing the corner hook by pulling the Rear Cover corner and
insert a jig or ruler.
② Ensure the jig or ruler is pulled backward.
③ DO NOT pivot on bezel when inserting the jig or ruler.
REAR COVER
Backward
OK
Do NOT pivot on bezel
NG
Bottom Hook Position
32
1
Ruler or jig to release corner hook
*Wrap ruler with tape to prevent scratch
80mm
137mm
313mm 157mm
150mm
SECTION 5: KD-75X8*K
TOOLS & EQUIPMENTS FFC PRECAUTIONS SECTION 1 SECTION 2 SECTION 3 SECTION 4 SECTION 5 SMART CORE APPENDIX
5-1. DISASSEMBLY AND REMOVAL CAUTION
SYSSET
2022/02/2522:04:10(GMT+09:00)

Sony KD-43X80K Specifications

General

Screen Size	43 inches
Display Type	LCD
Smart TV	Yes
Operating System	Google TV
HDMI Ports	4
USB Ports	2
Wi-Fi	Yes
Bluetooth	Yes
Refresh Rate	60 Hz
Processor	4K HDR Processor X1
Audio Output	20 W
Resolution	3840 x 2160
HDR	HDR10, HLG
Weight	9.8 kg (without stand)
