SET PART LIST
82
5-4. EXPLODED VIEW AND PART LIST
REF.
NO
PART NO. DESCRIPTION
KD-75X80K
KD-75X80CK
UCM LA8 UC2 LA1
1 5-039-295-71
LABEL, SIDE TERMINAL HP (EPH)
• n/a • •
1 5-039-295-31
LABEL, SIDE TERMINAL HP (EPH)
n/a • n/a n/a
2 4-745-608-01
AC COVER (AT)
n/a • n/a n/a
3 5-039-624-21
REAR COVER ASSY (3L LYX)
• n/a • •
3 5-039-624-71
REAR COVER ASSY (3L LYX)
n/a • n/a n/a
4 1-004-511-12
SP-BOX ASSY,FY20 W30XL-A
• • • •
5 1-004-511-22
SP-BOX ASSY,FY20 W30XL-B
• • • •
6 5-009-258-21
BRACKET, WIFI(BNN)
• • • •
7 1-005-419-32
WLAN/BT MODULE(11AC)FXC
• • • •
8 5-039-955-11
BRACKET SIDE (BNN) A
• n/a • •
8 5-039-955-01
BRACKET SIDE (BNN) A
n/a • n/a n/a
9
A-5042-741-A
COMPL_SVC_BM5A_FE_UCM
• n/a n/a n/a
9
A-5042-743-A COMPL_SVC_BM5A_FE_LAAR
n/a • n/a n/a
9
A-5042-742-A
COMPL_SVC_BM5A_FE_UCM_MIC
n/a n/a • •
10 4-457-451-12
SHEET, THERMAL (BAF)
• • • •
11 1-009-802-21
GL14P-STATIC CONVERTER (TV)
• n/a • •
11 1-009-802-11
GL14-STATIC CONVERTER (TV)
n/a • n/a n/a
12 5-027-742-11
SHEET, INSULATION (3L PHN) A
• n/a • n/a
12 5-009-271-11
SHEET, INSULATION (BNN 3L)
n/a • n/a •
SECTION 5: KD-75X8*K
REF.
NO
PART NO. DESCRIPTION
KD-75X80K
KD-75X80CK
UCM LA8 UC2 LA1
13 1-014-056-12
MOUNTED PWB E-T-CON (75)
• • • •
14
4-549-186-02 SHEET, THERMAL(BM)
• • • •
15 A-5043-474-A
P-MOD (YSCM075CCO02)
• • • •
16 5-022-231-13
STAND, L (3L LYX) A
• • • •
17 5-022-232-13
STAND, R (3L LYX) A
• • • •
TOOLS & EQUIPMENTS FFC PRECAUTIONS SECTION 1 SECTION 2 SECTION 3 SECTION 4 SECTION 5 SMART CORE APPENDIX
SYSSET
2022/02/2522:04:10(GMT+09:00)
