Withdrawal of 25P FFC (IRISO Connector)
Pre-Step Before FFC Removal
Push Smart Core outwards to dismantle from TV set
PUSH from TOP
PULL
2
1
Do NOT push from side as connector
will break due to excessive force applied.
1
2
Note: FFC as in image is only for reference purpose.
Actual FFC outlook may vary by each vendor.
Push the side-release lock buttons inward (highlighted in
red).
Pull-out FFC in straight direction while pushing side-
release lock buttons at the same time.
1
2
Step 1 & 2 Caution
APPENDIX
FFC REPLACEMENT CAUTIONS
TOOLS & EQUIPMENTS FFC PRECAUTIONS SECTION 1 SECTION 2 SECTION 3 SECTION 4 SECTION 5 SMART CORE APPENDIX
SYSSET
2022/02/2522:04:10(GMT+09:00)

Sony KD-43X80K Specifications

General

Screen Size	43 inches
Display Type	LCD
Smart TV	Yes
Operating System	Google TV
HDMI Ports	4
USB Ports	2
Wi-Fi	Yes
Bluetooth	Yes
Refresh Rate	60 Hz
Processor	4K HDR Processor X1
Audio Output	20 W
Resolution	3840 x 2160
HDR	HDR10, HLG
Weight	9.8 kg (without stand)
