FY17 2K System Block Diagram (KM)
5-2. Block Diagram
152
*Depends on destination
IF
TS
Ether
Composite
MT5581S
Ether
PHY
Demod
ATSC
DVB-T/C
DDR3 4G+4G
HP AMP
USB2.0 Port 0
USB2.0 Port 1
USB Stack
PCMCIA
P-TS
HDMI 1
(ARC)
SCART
*for Europe Region
Side-Key
I / O
CH/INPUT
D-AMP
LED Driver
(Standard)
DC-IN
BE
IC
Wi-Fi Module
USB2.0
2SP
LVDS
LED Backlight
19.5V from AC
adapter
I2C
PWM
I2C
HTL5-Board
(For Hotel model)
TBC
eMMC4.5
4GB
HDMI 2
H-Board
HP/A-OUT
MINI
JACK
*3Band-Mini-Jack
Component
(UC only) TBD
PCMIA
*for Europe Region
PMI
C
I2C
*Except EU
MHL
HP AMP
SPDIF
