56
KDL-46S2000
KDL-46S2000
NOTE: The components identifi ed by shading and
!
mark are critical for safety.
Replace only with part number specifi ed.
NOTE: Les composants identifi es per un trame et une marque
!
sont critiques pour
la securite. Ne les remplacer que par une piece portant le numero specifi e.
REF. NO. PART NO. DESCRIPTION [ASSEMBLY INCLUDES]
101 1-832-469-12 HARNESS WITH CONNECTOR (LVDS)
102 X-2109-045-2 BRACKET, (A,TU) (A) ASSEMBLY
103 1-826-435-11 LOUDSPEAKER (13X7CM)
104 4-660-752-01 TAPE (LCD)
(For S/N’s 7,000,001 ~)
104 2-688-062-01 TAPE (LCD)
(For S/N’s 8,000,001 ~)
!
105 1-819-729-13 INLET, AC (WITH NOISE FILTER)
106 2-664-617-01 BRACKET,G2
4-3. SPEAKERS
2-596-649-01 +KTT 3X10 (S TYPE)5
2-674-965-11 SCREW, +PSW 3SG
103
106
103
102
101
104
105
To Next Page
