109
REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
The components identified by
shading and marked are critical
for safety
Replace only with the part number
specified.
R5351 1-247-807-31 CARBON 100 5% 1/4W
R5352 1-249-416-11 CARBON 820 5% 1/4W
R5353 1-249-421-11 CARBON 2.2K 5% 1/4W
R5354 1-249-418-11 CARBON 1.2K 5% 1/4W
R5355 1-535-143-61 LEAD, JUMPER (5.0MM)
R5356 1-208-790-11 METAL CHIP 2.2K 0.5% 1/10W
R5357 1-202-557-00 SOLID 220 20% 1/2W
R5358 1-215-929-11 METAL OXIDE 100K 5% 3W
R5359 1-249-433-11 CARBON 22K 5% 1/4W
R5360 1-249-424-11 CARBON 3.9K 5% 1/4W
R5361 1-249-431-11 CARBON 15K 5% 1/4W
R5362 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R5363 1-216-059-00 RES-CHIP 2.7K 5% 1/10W
R5364 1-216-658-11 METAL CHIP 2K 0.5% 1/10W
R5375 1-249-435-11 CARBON 33K 5% 1/4W
R5376 1-249-429-11 CARBON 10K 5% 1/4W
R5377 1-249-430-11 CARBON 12K 5% 1/4W
R5378 1-249-429-11 CARBON 10K 5% 1/4W
R5379 1-249-438-11 CARBON 56K 5% 1/4W
R5380 1-249-433-11 CARBON 22K 5% 1/4W
R5381 1-216-055-00 RES-CHIP 1.8K 5% 1/10W
R5382 1-202-549-00 SOLID 100 20% 1/2W
R5383 1-216-399-00 METAL OXIDE 6.8 5% 3W
R5384 1-216-399-00 METAL OXIDE 6.8 5% 3W
R5385 1-202-549-00 SOLID 100 20% 1/2W
R5386 1-202-884-11 SOLID 820K 20% 1/2W
R5387 1-202-884-11 SOLID 820K 20% 1/2W
R5388 1-215-911-11 METAL OXIDE 100 5% 3W
R5389 1-249-417-11 CARBON 1K 5% 1/4W
< VARIABLE RESISTOR >
RV5375 1-241-656-21 RES, ADJ, METAL FILM 110M
RV5376 1-230-641-11 RES, ADJ, METAL GLAZE 2.2M
1-695-915-11 TAB (CONTACT)
4-201-023-01 SPACER, INSULATING
4-202-373-01 SPRING, IC
4-382-854-11 SCREW (M3X10), P, SW (+)
*4-931-401-01 HEAT SINK, V.OUT
< CAPACITOR >
C6600 £ 1-113-927-11 CERAMIC 10000PF 20.00% 250V
C6603 1-126-933-11 ELECT 100UF 20.00% 16V
C6604 1-126-767-11 ELECT 1000UF 20.00% 16V
C6605 £ 1-119-888-51 CERAMIC 2200PF 20.00% 250V
C6606 £ 1-119-888-51 CERAMIC 2200PF 20.00% 250V
C6607 £ 1-107-565-11 FILM 0.33UF 20.00% 300V
C6608 £ 1-161-964-91 CERAMIC 0.0047UF 250V
C6609 £ 1-161-964-91 CERAMIC 0.0047UF 250V
C6610 £ 1-161-964-91 CERAMIC 0.0047UF 250V
C6611 £ 1-161-964-91 CERAMIC 0.0047UF 250V
C6612 1-113-927-11 CERAMIC 10000PF 20.00% 250V
C6616 1-164-625-11 CERAMIC 680PF 10.00% 500V
C6617 1-164-625-11 CERAMIC 680PF 10.00% 500V
C6618 1-136-175-00 FILM 0.68UF 5.00% 50V
C6619 1-137-194-81 FILM 0.47UF 5.00% 50V
C6620 1-136-618-11 FILM 0.047UF 5.00% 1.25KV
C6621 1-136-175-00 FILM 0.68UF 5.00% 50V
C6622 1-164-625-11 CERAMIC 680PF 10.00% 500V
C6623 1-137-194-81 FILM 0.47UF 5.00% 50V
C6624 1-126-968-11 ELECT 100UF 20.00% 50V
C6626 1-164-625-11 CERAMIC 680PF 10.00% 500V
C6627 1-164-625-11 CERAMIC 680PF 10.00% 500V
C6628 1-126-936-11 ELECT 3300UF 20.00% 16V
C6629 1-128-548-11 ELECT 4700UF 20.00% 25V
C6630 1-110-626-11 ELECT 330UF 20.00% 160V
C6631 1-126-955-11 ELECT 4700UF 20.00% 35V
C6632 1-126-955-11 ELECT 4700UF 20.00% 35V
C6634 1-136-165-00 FILM 0.1UF 5.00% 50V
C6635 1-104-664-11 ELECT 47UF 20.00% 25V
C6636 1-102-129-00 CERAMIC 0.01UF 10.00% 50V
C6637 1-102-129-00 CERAMIC 0.01UF 10.00% 50V
C6638 1-137-368-11 MYLAR 0.0047UF 5.00% 50V
C6639 1-102-228-00 CERAMIC 470PF 10.00% 500V
C6641 1-126-967-11 ELECT 47UF 20.00% 50V
C6642 1-128-551-11 ELECT 22UF 20.00% 25V
C6647 1-104-664-11 ELECT 47UF 20.00% 25V
C6649 1-126-965-11 ELECT 22UF 20.00% 50V
C6651 1-161-964-91 CERAMIC 0.0047UF 250V
C6653 1-126-968-11 ELECT 100UF 20.00% 50V
C6654 1-162-117-00 CERAMIC 100PF 10.00% 500V
C6655 1-107-974-11 CERAMIC 47PF 5.00% 2KV
C6656 1-126-967-11 ELECT 47UF 20.00% 50V
C6657 1-126-941-11 ELECT 470UF 20.00% 25V
C6658 1-104-665-11 ELECT 100UF 20.00% 25V
C6659 1-104-665-11 ELECT 100UF 20.00% 25V
*A-1640-328-A D Board, Complete
(KV-28FX65)
*A-1640-399-A D Board, Complete
(KV-32FX65B/32FX65E/32FX65K)
*A-1640-323-A D Board, Complete
(KV-32FX65U)
D Board, Common Parts
D
C
To Next Page
