REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
The components identified by
shading and marked are critical
for safety
Replace only with the part number
specified.
D
D6625 8-719-991-33 DIODE 1SS133T-77
D6626 8-719-991-33 DIODE 1SS133T-77
D6627 8-719-982-27 DIODE MTZJ-T-77-33C
D6628 8-719-109-97 DIODE MTZJ-T-77-6.8
D6629 8-719-991-33 DIODE 1SS133T-77
D6630 8-719-991-33 DIODE 1SS133T-77
D6631 8-719-991-33 DIODE 1SS133T-77
D6651 8-719-068-00 DIODE ERC04-06SE
D6653 8-719-063-73 DIODE D1NL20U-TR
D6654 8-719-059-23 DIODE P6KE200AG23
D6655 8-719-979-64 DIODE UF4005PKG23
D6656 8-719-063-73 DIODE D1NL20U-TR
D6658 8-719-068-00 DIODE ERC04-06SE
D6659 8-719-063-73 DIODE D1NL20U-TR
D6676 8-719-991-33 DIODE 1SS133T-77
D6677 8-719-921-40 DIODE MTZJ-T-77-4.7B
D6678 8-719-921-40 DIODE MTZJ-T-77-4.7B
D6679 8-719-991-33 DIODE 1SS133T-77
D6681 8-719-991-33 DIODE 1SS133T-77
D6700 8-719-200-02 DIODE ERA15-02TP1
D6701 8-719-110-41 DIODE MTZJ-T-77-15B
D6803 8-719-920-35 DIODE ERA15-02TP1
D6804 1-535-143-11 LEAD, JUMPER (10.0MM)
D6805 8-719-302-43 DIODE RGP10GPKG23
D6806 8-719-979-85 DIODE RGP15GPKG23
D6807 8-719-510-73 DIODE S3L20UF4
D6808 8-719-510-73 DIODE S3L20UF4
D6809 8-719-991-33 DIODE 1SS133T-77
D6810 1-247-895-91 CARBON 470K 5% 1/4W
D6811 8-719-110-41 DIODE MTZJ-T-77-15B
D6851 8-719-970-87 DIODE ERA38-06TP1
D6852 8-719-970-87 DIODE ERA38-06TP1
< FERRITE BEAD >
FB6602 1-410-396-41 FERRITE 0.45UH
FB6603 1-410-396-41 FERRITE 0.45UH
< IC >
IC6600 1-810-051-11 POWER MODULE DM-48
IC6604 8-729-045-40 TRANSISTOR MX0842A-F
IC6651 8-759-468-89 IC TOP209P
IC6652 8-759-394-35 IC BA12T
IC6653 8-759-574-77 IC KA78R09-YDTU
IC6654 8-759-574-76 IC KA78R05-SYDTU
IC6667 8-759-908-15 IC TL431CZ
IC6676 8-759-908-15 IC TL431CZ
IC6700 8-759-192-71 IC STV9379
IC6801 8-759-103-93 IC LM393P
< COIL >
L6604 1-412-525-31 INDUCTOR 10UH
L6605 1-412-523-41 INDUCTOR 6.8UH
L6606 1-412-525-31 INDUCTOR 10UH
L6651 1-414-183-41 INDUCTOR 10UH
L6700 1-412-524-11 INDUCTOR 8.2UH
L6801 1-412-519-11 INDUCTOR 3.3UH
L6802 1-412-519-11 INDUCTOR 3.3UH
L6803 1-412-533-41 INDUCTOR 47UH
L6805 1-408-947-00 INDUCTOR 2.2MH
L6806 1-535-143-61 LEAD, JUMPER (5.0MM)
L6807 1-410-397-21 FERRITE 1.1UH
L6851 1-535-143-61 LEAD, JUMPER (5.0MM)
< FILTER >
LF6603 1-406-659-11 INDUCTOR 10UH
LF6604 1-406-659-11 INDUCTOR 10UH
LF6801 1-406-985-11 INDUCTOR 2.2MH
LF6851 1-406-674-11 INDUCTOR 3.3MH
< IC LINK >
PS6601 £ 1-801-550-21 PROTECTOR, MODULE 2.5A MP250
PS6602 £ 1-801-550-21 PROTECTOR, MODULE 2.5A MP250
PS6603 £ 1-801-549-21 PROTECTOR, MODULE 4.0A MP250
PS6604 £ 1-801-550-21 PROTECTOR, MODULE 2.5A MP250
< TRANSISTOR >
Q6600 8-729-046-47 TRANSISTOR KSC2500-BTA
Q6602 8-729-026-39 TRANSISTOR 2SA933AS-RT
Q6603 8-729-119-78 TRANSISTOR 2SC1740S-RT
Q6605 8-729-046-47 TRANSISTOR KSC2500-BTA
Q6606 8-729-029-56 TRANSISTOR DTA144ESA-TP
Q6607 8-729-119-78 TRANSISTOR 2SC1740S-RT
Q6608 8-729-029-66 TRANSISTOR DTC114ESA-TP
Q6611 8-729-029-66 TRANSISTOR DTC114ESA-TP
Q6651 8-729-026-39 TRANSISTOR 2SA933AS-RT
Q6652 8-729-029-86 TRANSISTOR DTC124ESA-TP
Q6667 8-729-026-39 TRANSISTOR 2SA933AS-RT
Q6676 8-729-119-78 TRANSISTOR 2SC1740S-RT
Q6677 8-729-119-78 TRANSISTOR 2SC1740S-RT
Q6678 8-729-119-78 TRANSISTOR 2SC1740S-RT
Q6679 8-729-026-39 TRANSISTOR 2SA933AS-RT
Q6680 8-729-029-66 TRANSISTOR DTC114ESA-TP
Q6681 8-729-029-66 TRANSISTOR DTC114ESA-TP
Q6700 8-729-039-68 TRANSISTOR IRF620
