COMPACT DISC DECK RECEIVER
US Model
Canadian Model
HCD-D290/G3300
AEP Model
UK Model
E Model
Australian Model
PX Model
HCD-XB3
– Continued on next page –
HCD-D290, HCD-G3300, HCD-XB3 is the
tuner, deck, CD and amplifier section in
LBT-D290, LBT-G3300, LBT-XB3.
Model Name Using Similar Mechanism NEW
CD Mechanism Type
CDM37L-5BD29AL
Base Unit Name BU-5BD29AL
Optical Pick-up Name
KSS-213D/Q-NP
Model Name Using
Similar Mechanism HCD-H881
Tape Transport Mechanism Type TCM-220WR2
CD
Section
Tape deck
Section
SPECIFICATIONS
Photo: HCD-XB3
Peak music power output
Argentine, Australian, E, Mexican,
PX models: 1000 watts
Music power output
AEP, UK, East European models: 100+100 watts
Inputs
PHONO IN (phono jack): sensitivity 3 mV, impedance 47 kilohms
VIDEO (AUDIO) IN (phono jack):sensitivity 250 mV, impedance 47 kilohms
MIX MIC (phono jack): sensitivity 1 mV, impedance 10 kilohms
Outputs
PHONES (stereo phone jack): accepts headphones of 8 odms or more
SPEAKER:
US, Canadian models: accepts impeadance of 8 to 16 ohms.
Other models accepts impeadance of 6 to 16 ohms.
For the U.S. model
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC DISTORTION:
With 8 ohm loads, both channels driven, from 70-20,000 Hz; rated 100 watts
per channel minimum RMS power, with no more than 0.9 % total harmonic
distortion from 250 milliwatts to rated output.
Amplifier section
DIN power output
AEP, UK, East European models: 55+55 watts (6 ohms at 1 kHz, DIN)
Continuous RMS power output
Canadian model: 100+100 watts
(8 ohms at 1 kHz, 5%)
Argentine, Australian, E, Mexican,
PX models: 70+70 watts
(6 ohms at 1kHz, 10% THD)
AEP, UK, East European models: 65+65 watts
(6 ohms at 1kHz, 100% THD)
HCD-D290/G3300/XB3
To Next Page
