Dimensions
40
LMD-A240/A220
Unit: mm (inches)
Make sure to tighten the screws using the screwdriver
which conforms to the supplied screws.
When using an electric screwdriver, set the torque
setting as follows.
For M4 screws: approximately 1.2 N·m [12 kgf·cm]
When installing on a vehicle, secure the unit to the
vehicle using the M4 screw holes on the sides of the
unit.
(The tilt angle is within 10° of the angle of depression)
LMD-A180
Front
Rear
Side
Unit: mm (inches)
Mass:
Approx. 4.8 kg (10 lb 9.3 oz)
* Length of M4 screws (side, rear)
Monitor cabinet
Attached object
M4 screw
6 (
1
/
4
) to 8 (
11
/
32
)
100 (4)
100 (4)
420
(16
5
/8)
71.6
(2
7
/8)
80
(3
1
/4)
80
(3
1
/4)
137.7 (5
1
/2)
# 6-M4 hole
Ventilation holes
(exhaust)
Ventilation holes
(intake)
* 4-M4 hole
70
(2
7
/
8
)
40
(1
5
/
8
)
25.9
(1
1
/
16
)
137.7
(5
1
/
2
)
235.4
(9
3
/
8
)
54.3
(2
1
/
4
)
165
(6
1
/
2
)
To Next Page
