Location and Function of Parts and Controls
8
Rotary encoder/MANUAL buttons
Value input button
Function buttons
Note
You can simultaneously connect up to 3 units of BKM-
16R or BKM-17R to this unit.
Knob Operations
CONTRAST knob Adjusts the picture contrast.
BRIGHT knob Adjusts the picture brightness.
CHROMA knob Adjusts the color intensity.
PHASE knob Adjusts the color tones only when the
composite input signal is NTSC format.
Button Operations
CONTRAST
MANUAL button
It is not available in this unit.
BRIGHT MANUAL
button
It is not available in this unit.
CHROMA MANUAL
button
It is not available in this unit.
PHASE MANUAL
button
It is not available in this unit.
Button Operations
1 to 9 button Turns on or off functions assigned to
the numeric buttons from 1 to 9 on the
controller.
The factory default settings are
following:
1 button: [SDI1]
2 button: [SDI2]
3 button: [HDMI]
4 button: [Composite]
5 button: (Disable)
6 button: (Disable)
7 button: (Disable)
8 button: (Disable)
9 button: (Disable)
Ent button Operates similar to the ENTER button
on the controller.
Button Operations
F1 to F16 button Turns on or off functions assigned to
the function buttons on the controller.
The following functions are available.
[16:9], [Marker], [Mono], [Blue Only],
[Chroma Up], [Side by Side], [Wipe],
[Blending], [Native Scan], [WFM/
ALM/Vector], [Time Code]
