Other Information
29-GB
To write-protect data
The tab on “Memory Stick” allows you to prevent from accidentally
changing the data stored on it.
By sliding the tab from side to side, the write-protection tab changes from
write enable to write protect.
• Write-free
Allows you to write data.
• Write-protected
By sliding the tab to the right, the write-protection changes to write
protect.
Data can be read, but not written.
The rear side of “Memory Stick”
Write-free Write-protected
Specifications
MG Memory Stick Reader/Writer
Interface: USB interface
Operating voltage 5V DC (supplied from USB cable)
Current consumption Action Max. 100 mA
Standby Max. 500 µA
External dimensions Approx. 68 × 20 × 108 mm (w/h/d)
Mass Approx. 65 g
Operating environment 0 ˚C to 40 ˚C (condensation not allowed)
