Chapter 8: Appendix: Specifications

Pin Assignments

TALLY connector

1 2 3 4 5

6 7 8 9

Pin No. GPI Description

Function Target Specifications

1 OUT PGM OUT TALLY INPUT1 (SDI) On: SHORT, Off: OPEN

2 OUT PGM OUT TALLY INPUT2 (SDI) On: SHORT, Off: OPEN

3 OUT PGM OUT TALLY INPUT3 (SDI) On: SHORT, Off: OPEN

4 OUT PGM OUT TALLY INPUT4 (SDI) On: SHORT, Off: OPEN

5 OUT PGM OUT TALLY INPUT1 (VIDEO) On: SHORT, Off: OPEN

6 OUT PGM OUT TALLY INPUT2 (VIDEO) On: SHORT, Off: OPEN

7 OUT PGM OUT TALLY INPUT3 (HDMI) On: SHORT, Off: OPEN

8 OUT PGM OUT TALLY INPUT4 (HDMI) On: SHORT, Off: OPEN

9 – GND – –
