— 13 —
< TRANSISTOR >
Q301 8-729-230-49 TRANSISTOR 2SC2712-YG
Q302 8-729-230-49 TRANSISTOR 2SC2712-YG
Q303 8-729-230-49 TRANSISTOR 2SC2712-YG
Q304 8-729-230-49 TRANSISTOR 2SC2712-YG
Q305 8-729-230-49 TRANSISTOR 2SC2712-YG
Q306 8-729-920-31 TRANSISTOR DTC343TK
Q307 8-729-230-49 TRANSISTOR 2SC2712-YG
Q308 8-729-040-78 TRANSISTOR DTA124GKA-T146
Q309 8-729-027-36 TRANSISTOR DTA143XKA-T146
< RESISTOR >
R301 1-216-857-11 METAL CHIP 1M 5% 1/16W
R302 1-216-101-00 METAL CHIP 150K 5% 1/10W
R303 1-216-081-00 METAL CHIP 22K 5% 1/10W
R304 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R305 1-216-101-00 METAL CHIP 150K 5% 1/10W
R306 1-216-853-11 METAL CHIP 470K 5% 1/16W
R307 1-216-845-11 METAL CHIP 100K 5% 1/16W
R308 1-216-089-91 RES,CHIP 47K 5% 1/10W
R309 1-216-841-11 METAL CHIP 47K 5% 1/16W
R310 1-216-817-11 METAL CHIP 470 5% 1/16W
R311 1-216-821-11 METAL CHIP 1K 5% 1/16W
R312 1-216-853-11 METAL CHIP 470K 5% 1/16W
R313 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R314 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R315 1-216-830-11 METAL CHIP 5.6K 5% 1/16W
R316 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R317 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R318 1-216-831-11 METAL CHIP 6.8K 5% 1/10W
R319 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R320 1-216-845-11 METAL CHIP 100K 5% 1/16W
R321 1-216-843-11 METAL CHIP 68K 5% 1/16W
R322 1-216-843-11 METAL CHIP 68K 5% 1/16W
R323 1-216-859-11 RES,CHIP 1.5M 5% 1/16W
R324 1-216-033-00 METAL CHIP 22 5% 1/10W
R325 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R326 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R327 1-216-809-11 METAL CHIP 100 5% 1/16W
R328 1-216-835-11 METAL CHIP 15K 5% 1/16W
R329 1-216-001-00 METAL CHIP 10 5% 1/10W
R330 1-216-001-00 METAL CHIP 0 5% 1/10W
R331 1-216-097-91 RES,CHIP 100K 5% 1/10W
R334 1-216-845-11 METAL CHIP 100K 5% 1/16W
R335 1-216-029-00 METAL CHIP 150 5% 1/10W
R342 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R345 1-216-841-11 METAL CHIP 47K 5% 1/16W
R348 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R349 1-216-001-00 METAL CHIP 10 5% 1/10W
R350 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R360 1-216-837-91 METAL CHIP 22K 5% 1/16W
< VARIABLE RESISTOR >
RV301 1-223-968-11 RES, VAR, CARBON 20K/20K (VOL)
RV302 1-225-641-11 RES, VAR, CARBON 10K (TUNING)
RV303 1-238-601-11 RES, ADJ, CARBON 22K (SEPARATION)
************************************************************
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
MISCELLANEOUS
*************
MDD01 1-505-117-21 RECEIVER (L-CH)
MDD02 1-505-117-21 RECEIVER (R-CH)
SW1 1-771-249-11 SWITCH, PUSH (1 KEY)(POWER)
************************************************************
*************
HARDWARE LIST
*************
#1 7-685-106-19 SCREW +P2X10 TYPE2 NON-SLIT
#2 7-685-105-19 SCREW +P2X8 TYPE2 NON-SLIT
#3 7-685-107-19 SCREW +P2X12 TYPE2 NON-SLIT
