Perform the following procedures 1 to 7 to hook up your system using the supplied cords and
accessories. MHC-RV55 is used for illustration purpose.
1 Connect the front speakers.
Connect the right and left speaker cords to
the SPEAKER (FRONT SPEAKER for
MHC-RV555/RV55) terminals as shown
below.
2 Connect the surround speakers.
(MHC-RV555/RV55 only)
Connect the speaker cords to SURROUND
SPEAKER terminals as shown below.
Getting Started
Hooking up the system
AM loop antenna
Front speaker (right)
Front speaker (left)
FM lead antenna
Surround speaker* (right)
Surround speaker* (left)
MHC-RV555/RV55 only
R
L
+
–
Black/Stripe (#)
Red/Solid
(3)
Insert only the stripped portion
Red
Black
+
–
R
L
Black/Stripe (#)
Red/Solid
(3)
Insert only the stripped portion
Blue
Black
continued
To Next Page
