SERVICE MANUAL
Sony CONFIDENTIAL
For Authorized Servicer
HOME AUDIO SYSTEM
US Model
Canadian Model
AEP Model
UK Model
E Model
Australian Model
Ver. 1.1 2020.08
MHC-V13
SPECIFICATIONS
– Continued on next page –
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC DISTORTION:
(US models only)
Left/Right Channel:
With 6 ohm loads, both channels driven, from 2,600 Hz – 20,000 Hz;
rated 10 watts per channel minimum RMS power at stereo mode,
with no more than 0.7% total harmonic distortion from 250 milliwatts
to rated output.
Speaker section
Speaker system:
2-way, Bass Reflex
Speaker unit:
Tweeter L/R: 50 mm (2 in), horn type
Woofer: 200 mm (8 in), cone type
Inputs
AUDIO IN:
Voltage 2 V, impedance 47 kilohms
MIC/GUITAR:
Sensitivity 1 mV, impedance 10 kilohms
(when guitar mode is turned off )
Sensitivity 200 mV, impedance 1 Megaohm
(when guitar mode is turned on)
Disc player section
System:
Compact disc and digital audio system
Laser Diode Properties
Emission Duration: Continuous
Wavelength: 790 nm
Laser Output*: Less than 44.6 μW
* This output is the value measurement at a distance
of 100 mm from the objective lens surface on the
Optical Pick-up Block with 7 mm aperture.
Frequency response:
20 Hz – 20 kHz
USB section
Supported USB device:
Mass Storage Class
Maximum current:
1 A
(USB) port:
Type A
FM tuner section (Except AEP, UK)
FM stereo, FM superheterodyne tuner
Antenna:
FM lead antenna (aerial)
Tuning range:
87.5 MHz – 108.0 MHz (50 kHz step) (Except US, CND)
87.5 MHz – 108.0 MHz (100 kHz step) (US, CND)
DAB/DAB+/FM tuner section (AEP, UK)
Antenna:
DAB/FM lead antenna (aerial)
Frequency range:
DAB/DAB+ (Band-III): 174.928 (5A) MHz – 239.200
(13F) MHz
FM: 87.5 MHz – 108.0 MHz (50 kHz step)
DAB/DAB+ frequency table (Band-III)
Fre-
quency
Label
Fre-
quency
Label
Fre-
quency
Label
174.928
MHz
5A
197.648
MHz
8B
220.352
MHz
11C
176.640
MHz
5B
199.360
MHz
8C
222.064
MHz
11D
178.352
MHz
5C
201.072
MHz
8D
223.936
MHz
12A
180.064
MHz
5D
202.928
MHz
9A
225.648
MHz
12B
181.936
MHz
6A
204.640
MHz
9B
227.360
MHz
12C
183.648
MHz
6B
206.352
MHz
9C
229.072
MHz
12D
185.360
MHz
6C
208.064
MHz
9D
230.784
MHz
13A
187.072
MHz
6D
209.936
MHz
10A
232.496
MHz
13B
188.928
MHz
7A
211.648
MHz
10B
234.208
MHz
13C
190.640
MHz
7B
213.360
MHz
10C
235.776
MHz
13D
192.352
MHz
7C
215.072
MHz
10D
237.488
MHz
13E
194.064
MHz
7D
216.928
MHz
11
A
239.200
MHz
13F
195.936
MHz
8A
218.640
MHz
11B
BLUET
OOTH section
Communication system:
BLUETOOTH Standard version 4.2
Output:
BLUETOOTH Standard Power Class 2
Maximum output power:
<9.5 dBm
Maximum number of devices to be registered:
8 devices
Maximum number of simultaneous connection (Multipoint):
3 devices
Maximum communication range:
Line of sight approx. 10 m (32 ft)
1)
Frequency band:
2.4 GHz band (2.4000 GHz – 2.4835 GHz)
Modulation method:
FHSS (Freq Hopping Spread Spectrum)
Compatible BLUETOOTH profiles
2)
:
A2DP (Advanced Audio Distribution Profile)
AVRCP (Audio Video Remote Control Profile)
Supported codecs:
SBC (Subband Codec)
AAC (Advanced Audio Coding)
LDAC
1)
The actual range will vary depending on factors such as
obstacles between devices, magnetic fields around a micro-
wave oven, static electricity, reception sensitivity, anten-
na’s performance, operating system, software application,
etc.
2)
BLUETOOTH standard profiles indicate the purpose of
BLUETOOTH communication between devices.
Supported audio formats
Supported bit rate and sampling frequencies:
MP3:
32/44.1/48 kHz, 32 kbps – 320 kbps (VBR)
AAC:
8/11.025/12/16/22.05/24/32/44.1/48 kHz,
8 kbps – 320 kbps (VBR)
WMA:
8/11.025/16/22.05/32/44.1/48 kHz,
48/64/96/128/160/192 kbps (CBR),
64 kbps – 161 kbps (VBR)
WAV:
8/11.025/12/16/22.5/24/32/44.1/48 kHz (16 bit)
Model Name Using Similar Mechanism MHC-V02
Optical Pick-up Name EM101VBS
SYSSET
2020/09/0901:02:55(GMT+09:00)
