Specifications
Model Name NSX- 46GT1 40GT1 32GT1 24GT1
System
Television system NTSC: American TV standard
ATSC (8VSB terrestrial): ATSC compliant 8VSB
QAM on cable: ANSI/SCTE 07 2000 (Does not include Cable CARD functionality)
Channel coverage Analog terrestrial: 2-69 / Digital terrestrial: 2-69
Analog Cable: 1-135 / Digital Cable: 1-135
Panel system LCD (Liquid Crystal Display) Panel
Speaker output 10W + 10W 5W + 5W
Input/Output jacks
CABLE/ANTENNA 75-ohm external terminal for RF inputs
VIDEO IN VIDEO / AUDIO
COMPONENT IN YPBPR (Component Video)/Signal format: 480i, 480p, 720p, 1080i, 1080p
AUDIO
HDMI IN 1/2/3/4 HDMI: Video:480i, 480p, 720p, 1080i, 1080p, 1080/24p
Audio: Two channel linear PCM 32, 44.1 and 48KHz, 16, 20 and 24bits, Dolby Digital
HEADPHONE Headphones jack
DIGITAL AUDIO OUT (OPTICAL) PCM/Dolby Digital optical signal
LAN 10BASE-T/100BASE-TX/1000BASE-T connector (Connection speed may differ depending on the
network environment. 10BASE-T/100BASE-TX/1000BASE-Tconnection rate and communication
quality are not guaranteed for this TV.)
USB USB jack Type A*
1
IR Blaster Mini jack (For connecting the IR Blaster cable)
Power and others
Power requirements 120 V AC, 60 Hz
Power consumption
in use 147 W 122 W 85 W 84 W
in DAM*
2
56 Wh/d 34 Wh/d 27 Wh/d
in standby less than 0.5 W
Screen size
(inches measured diagonally)
46 inches 40 inches 31.5 inches (32 class) 23.5 inches (24 class)
Display resolution 1,920 dots (horizontal) x 1,080 (vertical)
Speaker
Full range with speaker (mm) 45 × 130 45 × 130 45 × 130 34 × 105
(inches) 1
13
/16 × 5
1
/8 1
13
/16 × 5
1
/8 1
13
/16 × 5
1
/8 1
3
/8 × 4
1
/4
Dimensions
with stand (mm) 1,087 × 694 × 298 954 × 619 × 298 766 × 511 × 194 571 × 381 × 190
(inches) 42
7
/8 × 27
3
/8 × 11
3
/4 37
5
/8 × 24
3
/8 × 11
3
/4 30
1
/4 × 20
1
/8 × 7
3
/4 22
1
/2 × 15 × 7
1
/2
without stand (mm) 1,087 × 661 × 54 954 × 586 × 53 766 × 481 × 56 571 × 353 × 71
(inches) 42
7
/8 × 26
1
/8 × 2
1
/4 37
5
/8 × 23
1
/8 × 2
1
/8 30
1
/4 × 19 × 2
1
/4 22
1
/2 × 14 × 2
7
/8
wall-mount hole pattern
(mm)
300 × 300 300 × 300 200 × 200 100 ×100
wall-mount screw size
(mm)
M6 × 16 M6 × 16 M6 × 16 M4 × 12
Mass
with stand (kg)/(lb.) 22.7/50.1 18.8/41.5 13.2/29.2 10.1/22.3
without stand (kg)/(lb.) 21/46.4 17.1/37.7 11.8/26.1 8.7/19.2
