Setup Menu List
86
Menu Configuration and Detailed Settings
TC Format
Setting the time
code format
DF / NDF Set the timecode format.
DF: Drop frame
NDF: Non drop frame
Note
The current video format/frame frequency determines
whether the mode is fixed either to DF or NDF (see below),
regardless of the TC Format setting.
1)With DF, the frame digits can be set as desired in the range
of 00 to 29.
With NDF, the frame at the beginning of recording is
limited to 00, 05, 10, 15, 20, or 25.
2)The frame digits in “Setting” is limited to 00, 04, 08, 12, 16,
and 20.
The frame at the beginning of recording is limited to 00, 04,
08, 12, 16, or 20.
As “23.98P Output” (page 82) in the VIDEO SET menu
becomes 2-3 pull-down 59.94i when recording (or standing
by to record) HQ 1920×1080/23.98P other than when
“23.98PsF” is selected, the overlapping timecodes of frames
output from the SDI OUT connector are renumbered from
00 to 29.
3)Even in Clock mode, the timecode is gradually shifted,
because it is counted by NDF.
As output from the SDI OUT connector becomes 2-3
pulled-down video when recording (or standing by to
record) HQ 1920×1080/23.98P and other than “23.98PsF”
is selected for “23.98P Output” (page 82) in the VIDEO
SET menu, fields are created in which overlapping
timecodes are displayed on the screen.
TC/UB SET
Menu items Subitems and setting values Contents
Video formats Frame
setting
TC Format
59.94i
59.94P
29.97P
23.98P
1)
SP 1440×1080/
23.98P
HQ 1280×720/
23.98P
00 to 29 DF/NDF
switchable
(Fixed to DF in
Clock mode)
23.98P
HQ 1920×1080/
23.98P
HQ 1440×1080/
23.98P
HQ 1280×720/
23.98P
HD422 50/1080/
23.98P
HD422 50/720/
23.98P
00 to 23
2)
Fixed to NDF
3)
50i
50P
25P
00 to 24 Fixed to NDF
